Cisco SPA112 Administration Guide

Configuring the Voice Settings
Regional
Cisco SPA100Series Administration Guide 80
4
Referral Services
Codes
These codes tell the ATA what to do when the user places
the current call on hold and is listening to the second dial
tone.
One or more *codes can be configured into this parameter,
such as *98, or *97|*98|*123, etc. The maximum length is
79 characters. This parameter applies when the user
places the current call on hold by pressing the hook flash
button. Each *code (and the following valid target number
according to current dial plan) triggers the ATA to perform
a blind transfer to a target number that is prepended by
the service *code.
For example, after the user dials *98, the ATA plays a
special dial tone called the Prompt Tone while waiting for
the user the enter a target number (which is checked
according to dial plan as in normal dialing). When a
complete number is entered, the ATA sends a SIP INVITE
message with the Refer-To target equals to *98
target_number.This feature allows the ATA to hand off a
call to an application server to perform further processing,
such as call park.
The *codes should not conflict with any of the other
vertical service codes internally processed by the ATA.
You can empty the corresponding *code that you do not
want the ATA to process.
Default setting: blank
Field Description

Cisco SPA112 Specifications

General

Supported network protocols	IPv4, IPv6, ARP, DNS, SRV, DHCP, PPPoE, ICMP, TCP, UDP, RTP, RTCP, SNTP
DHCP client	Yes
VPN support	802.1p
Security algorithms	SSL/TLS
Authentication method	SIP
Modem (RJ-11) ports	2
Ethernet LAN (RJ-45) ports	1
Voice codecs	G.711, G.726, G.729
Certification	FCC, CE, ICES, A-Tick, RoHS, UL
Fax compatibility	T.38
Output current	2 A
Output voltage	5 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	101 mm
Height	28 mm
Weight	153 g
