Cisco SPA122 Administration Guide

Configuring the Voice Settings
User 1 and User 2
Cisco SPA100Series Administration Guide 104
4
Distinctive Ring Settings
Ring Settings
Media Loopback
Mode
The loopback mode to assume locally when making call to
request media loopback. Choices are: Source and Mirror.
Default setting: source
NOTE If the ATA answers the call, the mode is determined
by the caller.
Media Loopback
Typ e
The loopback type to use when making call to request
media loopback operation. Choices are Media and Packet.
Default setting: media
Note that if the ATA answers the call, then the loopback
type is determined by the caller (the ATA always picks the
first loopback type in the offer if it contains multiple type)
Field Description
Ring1 - 8 Caller Caller number pattern to play Distinctive Ring/CWT 1, 2, 3,
4, 5, 6, 7, or 8. Caller number patterns are matched from
Ring 1 to Ring 8. The first match (not the closest match)
will be used for alerting the subscriber. The distinctive
rings are set on the Regional page.
Default setting: blank
Field Description
Default Ring Default ringing pattern, 1–8, for all callers.
Default setting: 1
Default CWT Default CWT pattern, 1–8, for all callers.
Default setting: 1
Hold Reminder
Ring
Ring pattern for reminder of a holding call when the phone
is on-hook.
Default setting: 8
Call Back Ring Ring pattern for call back notification.
Default setting: 7
Field Description

Cisco SPA122 Specifications

General

Ports	2 FXS ports
Network Interface	10/100 Mbps Ethernet
Voice Protocol	SIP
Voice Codecs	G.711, G.726, G.729 A
Security	TLS
Power Supply	5V DC, 2A
Network Ports	1 x 10/100 Mbps
Fax Support	T.38 fax relay
Operating Temperature	0°C to 45°C
Storage Temperature	14 to 140°F (-10 to 60°C)
Humidity	10% to 90% noncondensing
Weight	0.16 kg
