Cisco SPA122 Administration Guide

Administration Settings
Diagnostics
Cisco SPA100Series Administration Guide 119
5
Diagnostics
The ATA includes two built-in diagnostic tools:
• Ping Test
• Traceroute Test
Ping Test
Use the Administration > Diagnostics > Ping Test page to test connectivity
between the ATA and a destination.
STEP 1 Enter the IP address or domain name that you want to ping.
STEP 2 Enter a packet size in bytes. The range is 32 to 65500 bytes.
STEP 3 Choose the number of times to send the ping request (5, 10, or Unlimited).
STEP 4 Click Start to Ping to start the test. After the test is complete, the test results
appear on the page. While the ping test is running, you can click Stop to abandon
the test.
The test results indicate the number of packets sent and received, the percentage
of packet loss, and the round-trip speed.
STEP 5 Click Close to close the test results and display the Ping Test form.
Traceroute Test
Use the Administration > Diagnostics > Traceroute page to view the route
between the ATA and a destination.
STEP 1 Enter the IP address or domain name of the destination.
STEP 2 Click Start to Traceroute to start the test. The results appear on the page and are
refreshed every 5 seconds. During the test, you can click Stop to abandon the test.
The results display up to 30 hops.
STEP 3 Click Close to close the results and display the Traceroute Test form.

Cisco SPA122 Specifications

General

Ports	2 FXS ports
Network Interface	10/100 Mbps Ethernet
Voice Protocol	SIP
Voice Codecs	G.711, G.726, G.729 A
Security	TLS
Power Supply	5V DC, 2A
Network Ports	1 x 10/100 Mbps
Fax Support	T.38 fax relay
Operating Temperature	0°C to 45°C
Storage Temperature	14 to 140°F (-10 to 60°C)
Humidity	10% to 90% noncondensing
Weight	0.16 kg
