Cisco TelePresence MX200 G2 Installation Guide

5
Read this before you mount the monitors
78-100574-02A0 | 2016 JUNE | © 2016 Cisco Systems, Inc. All rights reserved.
Installation guide for Cisco TelePresence MX800 Dual - Floor stand
Page 10
Right monitor, rearLeft monitor, rear
Use lifting handles
To avoid trapping your fingers, use the lifting
handles at the bottom of the monitor.
The screws with wing nut, which you
can see from the sides of the monitor,
must enter the center slot on each side
of the floor stand.
The monitors are heavy.
We recommend four people working
together to mount the monitors. Two
people should lift the monitor using the
handles as described below; the other
people must help stabilizing the monitor
and check that the monitor enters the
slots properly.
Applies to systems that are secured to the
wall: To assure that the camera can move
freely, fasten two bumpons on the rear of
the top profile, close to the camera.

Cisco TelePresence MX200 G2 Specifications

General

Resolution	1920 x 1080
Network	10/100/1000 Ethernet
Product Type	Video conferencing system
Display Size	42 in
Camera	PrecisionHD 1080p Camera
Codec	Cisco TelePresence Codec
Video Inputs	HDMI, DVI-I
Video Outputs	HDMI
Control	Cisco Touch 10
Video Standards	H.264
Connectivity	HDMI
Codec Support	H.264
Resolution (fps)	1080p30
