Tap and hold the selfview image. The selfview image will now turn blue. You
will also see the alternate positions available
for the selfview image. Keep holding the
image.
Release the image by lifting your nger from the
screen. The selfview image has now assumed its
new position.
Move the Selfview PiP
Camera
Selfview shows what others see
from your video system. You will
normally use it to conrm that they
see what you want them to see.
The selfview appears as a PiP
(Picture-in-Picture).
From time to time you may want
to have the selfview activated
during the meeting. This could, for
example, be to ensure that you
remain seen on the screen.
It may happen that the current
position of the selfview blocks
important parts of the image on your
screen. You may therefore want to
move it.
Why Move the Selfview?
1 2
3 4
Drag the image to a new position, shown here is
the upper left corner.

Cisco TelePresence Touch 10 Specifications

General

Resolution	1280 x 800
Touch Technology	Capacitive
Compatibility	Cisco TelePresence Systems
Power	Power over Ethernet (PoE)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Relative Humidity	10% to 90% (non-condensing)
Display Size	10.1 inches
Connectivity	Ethernet
Mounting	Tabletop
Weight	0.9 kg (1.98 lbs)
Storage Temperature	-20° to 60°C (-4° to 140°F)
