Cisco UCS C22 M3 Spec Sheet

Cisco UCS C22 M3 High-Density SFF Rack-Mount Server
18
CONFIGURING the SERVER
Select RAID Options
Select one RAID controller (either embedded RAID in Table 5 or hardware RAID using a PCIe RAID
controller and an appropriate RAID configuration option listed in Table 6 on page 18).
Table 5 Available Embedded RAID (LSI MegaSR) Options
Product ID (PID) PID Description
Embedded RAID
UCSC-RAID-ROM5 Onboard RAID, consisting of a plug-in storage controller unit (SCU), supporting
up to 8 internal SAS +SATA drives. SAS and SATA drives can be mixed. This option
supports RAID 0, 1, and 10, and operates at 3 Gb/s. Operating systems
supported are Windows and Linux only (no VMware support).
UCSC-RAID-ROM55 Onboard RAID, consisting of two plug-in modules (an SCU plus a software key
module) supporting up to 8 internal SAS+SATA drives. SAS and SATA drives can be
mixed. This option supports RAID 0, 1, 5, and 10 and operates at 3 Gb/s.
Operating systems supported are Windows and Linux only (no VMware support).
Table 6 Available Hardware RAID Options
Product ID (PID) PID Description
RAID Controllers
Note that PCIe RAID controllers are installed by default in slot 1 for 1-CPU systems and slot 2 for
2-CPU systems
UCSC-RAID-9240-8I LSI MegaRAID 9240-8i
■ Supports up to 8 internal SAS+SATA drives. SAS and SATA drives can be
mixed.
■ RAID levels supported: RAID 0, 1, 5, 10, 50 (see the RAID Configuration
Options section later in this table)
UCSC-RAID-9220-8I LSI MegaRAID 9220-8i
■ Supports up to 8 internal SAS+SATA drives. SAS and SATA drives can be
mixed.
■ RAID levels supported: RAID 0, 1, 10 (see the RAID Configuration Options
section later in this table)
NOTE: VMware ESX/ESXi or any other virtualized environments are not supported
for use with the embedded MegaRAID controller. Hypervisors such as Hyper-V, Xen, or
KVM are also not supported for use with the embedded MegaRAID controller
