Cisco UCS C22 M3 Spec Sheet

Cisco UCS C22 M3 High-Density SFF Rack-Mount Server
CONFIGURING the SERVER
19
UCSC-RAID-9220-4i LSI MegaRAID 9220-4i
■ Supports up to four internal SAS+SATA drives. SAS and SATA drives can be
mixed.
■ RAID levels supported: RAID 0, 1, 10 (see the RAID Configuration Options
section later in this table)
UCS-RAID9270CV-8i LSI MegaRAID 9270CV-8i (with supercap power backup)
■ Supports up to 8 internal SAS+SATA drives. SAS and SATA drives can be
mixed.
■ Includes a 1 GB Transportable Memory Module (TMM) cache and
chassis-mount (remote) supercap power module for data cache backup
■ RAID levels supported: RAID 0, 1, 5, 6, 10, 50, 60 (see the RAID
Configuration Options section later in this table)
RAID Configuration Options (not available for embedded RAID)
R2XX-RAID0 Factory preconfigured RAID striping option
Enable RAID 0 Setting. Requires a minimum of one hard drive.
R2XX-RAID1 Factory preconfigured RAID mirroring option
Enable RAID 1 Setting. Requires exactly two drives with the same size, speed,
capacity.
R2XX-RAID5 Factory preconfigured RAID option
Enable RAID 5 Setting. Requires a minimum of three drives of the same size,
speed, capacity.
R2XX-RAID6 Factory preconfigured RAID option
Enable RAID 6 Setting. Requires a minimum of four drives of the same size,
speed, capacity.
R2XX-RAID10 Factory preconfigured RAID option
Enable RAID 10 Setting. Requires an even number of drives (minimum of four
drives) of the same size, speed, capacity.
NOTE: Although RAID levels 50 and 60 are not orderable from the factory, they are
supported for selected controllers as shown in
Table 6.
Table 6 Available Hardware RAID Options (continued)
Product ID (PID) PID Description
