Fabric Extender: Cisco Nexus 2000 Series
Hardware Features
Cisco Nexus 2148T
Cisco Nexus 2000 Series Gigabit Ethernet Fabric Extenders Environment
Dimensions (Height x Width x Depth)
1.72 x 17.3 x 20.0 in.
(4.37 x 43.94 x 50.8 cm)
Weight
18 lb (8.2 kg)
* Systems are fully loaded with two power supplies
and one fan tray.
Indicator and Port Specification
Environment
Power Supply N2K-PAC-200W
Fan Tray N2K-C2148-FAN
Typical Input Operating Power 165W
Input Current
1.5A/2.2A (typical/maximum)
Note: Input currents listed for 110V;
divide by 2 for 220V
Supply will surge on AC power-up for a fraction
of a second beyond this rating
Output Current 11.5A/16.7A (typical/maximum)
Heat Dissipation 670 BTU/hr
Cisco Nexus 2248TP Cisco Nexus 2224TP Cisco Nexus 2232PP
1.72 x 17.3 x 17.7 in.
(4.37 x 43.94 x 44.96 cm)
1.72 x 17.3 x 17.7 in.
(4.37 x 43.94 x 44.96 cm)
1.72 x 17.3 x 17.7 in.
(4.37 x 43.94 x 44.96 cm)
17.7 lb (8.0 kg)
* Systems are fully loaded with two
power supplies and one fan tray.
16.6 lb (7.53 kg)
* Systems are fully loaded with two
power supplies and one fan tray.
18.3 lb (8.3 kg)
* Systems are fully loaded with two
power supplies and one fan tray.
System status: green (operational), amber (fault), flashing amber (POST boot up), off (no power)
Locator LED: bright blue locator
Port status: green (link established), amber (administratively disabled), flashing amber (fault)
Fan status: green (operational), amber (fault)
Power status: green (operational), amber (fault)
Operating temperature: 32 to 104°F (0 to 40°C)
Non-operating temperature: –4 to 158°F (–20 to 70°C)
Humidity: 5 to 95 percent (Noncondensing)
Altitude: 0 to 10,000 ft (0 to 3000m)
N2K-PAC-400W,
N2K-PAC-400W-B, and
N2K-PDC-400W
N2K-PAC-400W,
N2K-PAC-400W-B, and
N2K-PDC-400W
N2K-PAC-400W,
N2K-PAC-400W-B, and
N2K-PDC-400W
N2K-C2248-FAN and
N2K-C2248-FAN-B
N2K-C2248-FAN and
N2K-C2248-FAN-B
N2K-C2232-FAN and
N2K-C2232-FAN-B
110W 95W 270W
1.0A/1.2A (typical/maximum)
Note: Input currents listed for 110V;
divide by 2 for 220V
Supply will surge on AC power-up
for a fraction of a second beyond
this rating
0.75A/0.90A (typical/maximum)
Note: Input currents listed for 110V;
divide by 2 for 220V
Supply will surge on AC power-up
for a fraction of a second beyond
this rating
2.5A/4.1A (typical/maximum)
Note: Input currents listed for 110V;
divide by 2 for 220V
Supply will surge on AC power-up
for a fraction of a second beyond
this rating
8A/10A (typical/maximum) 5A/7A (typical/maximum) 20A/33A (typical/maximum)
322/403 BTU/hour
(typical/maximum)
201/282 BTU/hour
(typical/maximum)
806/1330 BTU/hour
(typical/maximum)
