Hardware Features
WS-C6503-E WS-C6504-E
Slots 3 4
Gigabit Ethernet GBIC/SFP Density 32/98 48/144
Two Chassis configured as a Virtual
Switching System (SFP Only)
196 288
10 GBE XENPAK/X2 Port Density 11170 17136
Two Chassis configured as a Virtual
Switching System
68 100
10/100/1000 Density 97 145
Two Chassis configured as a Virtual
Switching System
194 290
10/100 Density 192 288
100BASE-FX Density 96 144
10 Gigabit Ethernet RJ-45 port density 32 48
Maximum Watt Power Consumption (Redundant Mode)
AC Internal (Redundant Mode) 1400 2700
DC Internal (Redundant Mode) 950 2700
Maximum Number of Class 3 Devices (15.4W) Maximum Power Supplies
AC Internal (Redundant Mode) 48 110
DC Internal (Redundant Mode) 31 110
Dimension (H x W x D) Inches 7 x 17.37 x 21.75 8.75 x 17.5 x 21.75
Dimension (H x W x D) Centimeters 17.8 x 44.1 x 55.2 22.2 x 44.5 x 55.2
Rack Unit (RU) 4 5
Unit Weight Pounds (Kilograms)
(Chassis Only)
33 (15.0) 40 (18.1)
WS-C6506-E WS-C6509-E WS-C6509-V-E WS-C6513-E
6 9 9 13
80/242 128/386 128/384 240/528
484 772 768 1056
20/82 32/130 32/130 48/84
164 260 260 164
241 385 385 577
482 770 770 482
480 768 768 1152
240 384 384 576
80 128 128 80
8700 8700 8700 6000
4000 4000 4000 4000
284 288 215 281
173 184 206 176
19.2 x 17.5 x 18.2 24.5 x 17.5 x 18.2 33.3 x 17.2 x 18.1 33.3 x 17.3 x 18.1
48.8 x 44.5 x 46.0 62.2 x 44.5 x 46.0 84.6 x 43.7 x 46.0 84.6 x 43.7 x 46.0
12 15 21 20
50 (22.7) 60 (27.3) 55 (24.9) 98 (45.0)
