8
Introduction
Series Overview (continued)
Fixed-configuration Switches
Cisco Catalyst 3750-E Series
Stackable switches offering multilayer
switching and the enhanced Cisco
StackWise™ Plus technology for
enterprise branch offices and
mid-market organizations.
• Stackable fixed-configuration
switches featuring Cisco StackWise
Plus technology, a 64 Gbps
interconnect for a unified, resilient
system of up to nine switches
(including Cisco Catalyst 3750
Series switches)
• Layer 2–4 switching and intelligent
services with dynamic IP routing
and IPv6
• Gigabit Ethernet and upgradeable
Gigabit Ethernet to 10 GBE
connectivity
• Up to 48 10/100/1000 ports plus
two 10 GBE X2 ports per stackable
switch or four GBE ports
• Enhanced PoE support; the
capability to power beyond
15.4W per port
• AC power supply failure protection
with external power system
Cisco Nexus 5000 Series
The Cisco Nexus 5000 Series
Switches help you transform the data
center with innovative, standards-
based, multilayer, multiprotocol, and
multipurpose Ethernet-based fabric.
Now with the Unified Ports functionality
you can help enable any transport over
Ethernet, including Layer 2 and Layer
3 traffic, and storage traffic, all on one
common data center-class platform.
• Based on the Cisco
®
NX-OS
operating system, that is resilient,
efficient, virtualized and extensible
• High performance, low latency
system with up to 1.92 Tbps
switching fabric and 1428 Mpps
forwarding rate
• Front-to-back cooling supports
efficient data center hot- and
cold-aisle designs
• Unified ports provides flexibility in
choosing SAN and LAN port options
consistent with the virtualized data
center and offer a migration path
to FCoE
• LAN and SAN Convergence ready
through FCoE-based unified fabric
and Fibre Channel support in a
lossless Ethernet service platform.
Energy efficiency achieved with the
convergence of the networks
• Virtualization-aware networking
through virtualization optimized
services and mobility by mapping
virtual machines to network profiles
• Supports the extension of the fabric
extender technology into the servers
and virtual machines via Adapter
FEX and VM-FEX technologies.
Nexus 5000 Series Switches acts
as the single point of network
management for these servers and
virtual machines
• Pair with Nexus 5000 for up to 24
fabric extenders per Cisco Nexus
5548P switch
Cisco Catalyst 4900 Series
Fixed-configuration switches offering
high-performance and highest
availability in 1–2RU configuration,
optimized for data center top of rack
server aggregation and for space
constrained branch collapsed core/
distribution LAN aggregation.
• Standalone fixed-configuration
for low-latency and wire-speed
switching
• Wire-rate performance with 96-320
Gbps non-blocking switching fabric
• Layer 2–4 switching and intelligent
services with dynamic IP routing and
IPv6
• Configurations from 48 10/100/1000
ports to 24 10 GBE ports
• TwinGig converter module for
migrating from 1 Gigabit Ethernet
(SFP) to 10 GBE (X2) on 4900M
• Dual, hot-swappable internal AC or
DC power supplies
• Hot-swappable fan trays
Cisco Catalyst 3750-X Series
Enterprise-class stackable switches
with innovative features such as Cisco
StackPower, Power over Ethernet
Plus (PoE+), and MAC security.
for enterprise branch offices and
mid-market organizations.
• 24 and 48 10/100/1000 PoE+ and
non-PoE models with optional
four 1 GB Ethernet SFP or two 10
GB Ethernet SFP+ uplink network
modules
• PoE+ with 30W power on all ports
in 1 rack unit (RU)
• Cisco StackPower: Innovative,
9
Cisco Catalyst 3750 Series
Stackable switches offering multilayer
switching and Cisco StackWise™
technology for enterprise branch
offices and mid-market organizations.
• Stackable fixed-configuration
switches featuring Cisco StackWise
technology, a 32 Gbps interconnect
for a unified, resilient system of up to
nine switches
• Layer 2–4 switching and intelligent
services with dynamic IP routing and
IPv6
• Fast Ethernet, Gigabit Ethernet and
10 GBE connectivity
• Up to 48 10/100/1000 ports plus four
SFP ports per stackable switch
• Integrated PoE (Cisco pre-standard
and IEEE 802.3af); up to 24 ports with
15.4 watts or 48 ports with 7.3 watts
• AC power supply failure protection
with external power supply
Cisco Nexus 3000 Series
Cisco Nexus 3064 Switch is a high
performance, high density, sub-micro-
second latency ethernet switch, which
is part of the brand new Cisco Nexus
3000 Series Switches. This compact
1RU form factor 10GbE switch provides
wire-rate L2 and L3 switching and
future-proofs networks with 40GbE
standards-based technologies while
also being backward compatible with
1GbE. Cisco Nexus 3064 is ideal for
financial co-location deployments
requiring support for advanced unicast
and multicast routing protocol features
at ultra-low latency.
Cisco Nexus 3000 Series Switches
extends the comprehensive proven
innovations of Cisco Data Center
Business Advantage into the HFT
market too. The switch does so by
delivering functionalities such as
ultra-low latency and wire-rate L2/L3
switching on data center class NX-OS
operating system.
The key challenges addressed by the
Cisco Nexus 3000 series include:
• Increased application sensitivity to
network latency
• Increasing bandwidth requirements
due to increasing application
workloads
• Need for supporting advanced
routing protocols with resiliency
• Need to measure network latency
between servers
Key highlights of Cisco Nexus 3000
Series Switches:
• Ultra Low Latency
- Cisco Nexus 3000 Series Switches
delivers ultra-low latency that
translates to faster data transactions
thereby resulting in increased
revenue for the financial companies.
• Wire-rate 10 Gigabit Ethernet
Switching on all 64 10GbE ports
- Layer 2/3 switching up to 1.2Tbps,
over 950Mpps (Million Packets per
second) in a compact 1RU form
factor switch.
- Future-proof with 40GbE
standards-based support
• Purpose-built on NX-OS operating
system with comprehensive,
proven innovations
- Modular OS built from the ground
up for resiliency
- Full L3 routing protocol suites
including BGP, OSPF, EIGRP, RIPv2
- Integration with Cisco DCNM and
XML management tools
- Support for Precision Time
Protocol (IEEE-1588) to
synchronize system clocks with
nanosecond accuracy
industry-first feature for sharing
power among stack members
• Cisco StackWise Plus for ease of
use and resiliency with 64 Gbps
throughput
• Backward compatibility with
Catalyst 3750 Series
• Enhanced limited lifetime warranty
• MAC security hardware-based
encryption
• Multicast routing, IPv6 routing,
and access control list in hardware
• Support LAN Base, IP Base and IP
Services configurations
