Connecting to an HDTV with Component Input (YPbPr)
WARNING: Electric shock hazard! Unplug all electronic devices before connecting or disconnecting
any device cables to the set-top.
Required cables:
• 1 component video cable (YPbPr)
• 1 audio Left/Right cable
