2.3 Specifications
Item CBM-910-24* CBM-910-40*
1 Printing method Dot matrix
2 Printing direction One-way printing
3 Character configuration
(W × H) (5 + 1) × 8 (4 + 0.5) × 8
4 Number of columns per line 24 columns: 144 dot/line 40 columns: 180 dot/line
5 Printing speed Approx. 2.5 line/sec. Approx. 1.8 lines/sec.
6 Character size (W × H) 1.62 × 2.4 mm 1.08 × 2.4 mm
7 Line pitch 3.52 mm
8 Paper Paper Roll 57.5 ± 0.5(W) × 60 or 80 (Dia) mm
Core ID φ 12 ± 1 mm Core OD φ 18 ± 1mm *1
9 Interface Parallel Interface (Conformity to Centronics) or
Serial Interface (RS-232C)
10 Input buffer 2K bytes
11 Paper-end detection Printing suspended when printing paper gets scarce.
12 Ink ribbon Purple (Private ribbon cassette)
Service life: approx. 250,000 letters
13 Voltage DC 7V ± 1V (Printing)
Use exclusive adapter (DC 7V, 1.6A)
14 Power consumption Printing : approx. 7VA
Stand-by : approx. 0.5VA
15 Weight Approx. 400g
16 Reliability MCBF 1 million lines MCBF 700,000 lines
17 Dimension 106(W) × 180(D) × 88(H) mm
18 Operating temp.
0°C to 40°C
19 Storage temp
-20°C to 60°C
