CITIZEN Android Label Print SDK — Programming Manual
13
Methods (LabelDesign class)
No
Method
Description
1
LabelDesign
Constructor.
2
drawTextPtrFont
Draws text by using a printer device font.
3
drawTextDLFont
Draws text by using a downloaded font.
4
drawTextLocalFont
Draws text by using a font installed in the terminal.
5
drawNVBitmap
Draws a bitmap image stored in the flash memory of the printer.
6
drawBitmap
Draws a bitmap file in the computer.
7
drawBarCode
Draws a barcode.
8
drawMaxiCode
9
drawPDF417
10
drawDataMatrix
11
drawQRCode
12
drawAztec
13
drawGS1DataBar
14
drawLine
Draws a line.
15
drawRect
Draws a rectangular.
16
fillRect
Draws a rectangular filled with a specified pattern.
17
drawCircle
Draws a circle.
18
fillCircle
Draws a circle filled with a specified pattern.
19
drawPolygon
Draws a polygon.
20
fillPolygon
Draws a polygon filled with a specified pattern.
21
embedRawDesignCommand
Embeds raw printer commands.

Citizen CL-E300 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Product color	Black
Ethernet LAN	Yes
RS-232 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Flash memory	16 MB
Internal memory	32 MB
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Supported paper width	12.5 - 118 mm
LED indicators	Power, Status
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	60 W
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	208 mm
Width	170 mm
Height	152 mm
Weight	1980 g
