CITIZEN Android Label Print SDK — Programming Manual
75
2.3.12 drawAztec method
Syntax
int drawAztec (String data, int encoding, int rotation, int exp, int ECLevel, int x, int y)
Parameters
Parameter
[IN/OUT]
Description
Setting range
data
[IN]
String data
* The characters available with the specified
encoding.
encoding
[IN]
Character encoding
See #9 in "3.3.Predefined Constants."
rotation
[IN]
Direction of rotation
CLS_RT_NORMAL: No rotation
CLS_RT_RIGHT90: Rotate CW 90
CLS_RT_ROTATE180: Rotate CW 180
CLS_RT_LEFT90: Rotate CCW 90
exp
[IN]
Magnification
1-15
ECLevel
[IN]
Error correction level
CLS_AXTEC_EC_LEVEL_000:
Level 0 (Error correction ratio 23%)
x
[IN]
X-coordinate
0000-9999
* The origin is at bottom-left.(0, 0)
y
[IN]
Y-coordinate
Description
Draws the Aztec barcode with specifying options such as character encoding, rotation, magnification,
EC level and coordinates.
Return value
Returns CLS_SUCCESS(0) on success, an error code otherwise. See "2.1 Return value" for the error
codes.
Example
design.drawAztec("0123456789",
LabelConst.CLS_ENC_CDPG_US_ASCII,
LabelConst.CLS_RT_NORMAL, 10,
LabelConst.CLS_AXTEC_EC_LEVEL_000, 0, 0);

Citizen CL-E300 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Product color	Black
Ethernet LAN	Yes
RS-232 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Flash memory	16 MB
Internal memory	32 MB
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Supported paper width	12.5 - 118 mm
LED indicators	Power, Status
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	60 W
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	208 mm
Width	170 mm
Height	152 mm
Weight	1980 g
