CITIZEN Android Label Print SDK — Programming Manual
78
2.3.14 drawLine method
Syntax
int drawLine (int x1, int y1, int x2, int y2, int thickness)
Parameters
Parameter
[IN/OUT]
Description
Setting range
x1
[IN]
Start position
(X-coordinate)
0000-9999
* The origin is at bottom-left.(0, 0)
y1
[IN]
Start position
(Y-coordinate)
x2
[IN]
End position
(X-coordinate)
y2
[IN]
End position
(Y-coordinate)
thickness
[IN]
Line width (Reference point is
center)
0000-9999
Description
Draws a line of the specified width.
Start and stop positions will be located at the center of the line. Each coordinate must be within the
range of 0000-9999. Moreover the whole line image (rectangule) including the line thickness must
be within the range of 0000-9999 as well. Returns CLS_E_ILLEGAL(1101) otherwise.
Return value
Returns CLS_SUCCESS(0) on success, an error code otherwise. See "2.1 Return value" for the error
codes.
Example
// FormatAttribute:OR
printer.setFormatAttribute(1);
// Bar
design.drawLine(20, 30, 20, 300, 10);
// Horizontal line
design.drawLine(16, 34, 200, 34, 10);

Citizen CL-E300 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Product color	Black
Ethernet LAN	Yes
RS-232 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Flash memory	16 MB
Internal memory	32 MB
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Supported paper width	12.5 - 118 mm
LED indicators	Power, Status
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	60 W
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	208 mm
Width	170 mm
Height	152 mm
Weight	1980 g
