Citizen CMP-20 Service Manual

CMP-20 Service Manual
UPPER HOUSING ASM PARTS LIST
CMP-20 EXPLODE VIEW
No. Symbol Parts No. Description Q’ty Remarks
033 1 PM20MD-C002 UPPER HOUSING 1
034 2 PM20MD-C021 KEY POWER 1
035 3 PM20MD-C019 LENS LED 1
036 4 PM20MD-C020 KEY FEED 2
037 5 PM20PA-B004 PCB FUCNTION ASSEMBLY 1
039 7 TB 2.0 X5 SCREW 4
040 8 PM20PS-C005 BRACKET TEAR BAR 1
041 9 TB 2.0X3 납작 HEAD SCREW 2
042 10 PM20MD-C010 CAP DC 1
043 11 PM20MD-C011 CAP USB 1
