CMP-20 Service Manual
EXPLODE VIEW
TOP COVER ASM PARTS LIST
CMP-20 EXPLODE VIEW
No. Symbol Parts No. Description Q’ty Remarks
013 1 PM20MD-C003 TOP COVER 1
014 2 PM20MD-C005 WINDOW 1
015 3 PM20DG-C001
MECHNISM ASSEMBLY INCLUDING
PLATTEN ROLLER
1
016 4 TB 2.6 X 5 PH SCREW 4 BLACK
