Citizen CMP-20 Service Manual

CMP-20 Service Manual
PAPER TRAY ASM PARTS LIST
CMP-20 EXPLODE VIEW
No. Symbol Parts No. Description Q’ty Remarks
017 1 PM20MD-C004 PAPER TRAY 1
018 2 PM20DG-C002 MSR ASSEMBLY 1 OPTION
019 3 PM20DG-C001
MECHNISM ASSEMBLY INCLUDING
PLATTEN ROLLER
1
020 4 PM20PS-C002 LIFT SPRING 2
021 5 PM20CT-C002 CABLE SPACER 1
022 6 PM20WH-C001 CABLE GND 1
023 7 PM20CT-C003 SPRING BUTTON 1
024 8 PM20WH-C003 CABLE MSR 1
025 9 TB 2.0 X 8 (WASHER) SCREW 3
026 10 TB 2.0 X 6 SCREW 1

Citizen CMP-20 Specifications

General

Brand	Citizen
Model	CMP-20
Category	Printer
Language	English
