Citrix ADC MPX
Port Type LED LED LED Color LED Indicates
Amber Traic rate of 1
gigabit per
second.
Right Link/Activity O No link.
Solid yellow Link is
established but
no traic is
passing through
the port.
On each power supply, a bicolor LED indicator shows the condition of the power supply.
3Y power supply
The 3Y power supply is used on the following platforms:
• 450 W AC/DC
– MPX 8005/8010/8015
– MPX 8200/8400/8600/8800
• 850 W AC
– MPX 16000
• 1000 W AC/DC
– MPX 14000
– MPX 25000
– T1300
– MPX 15000
– MPX 15000‑50G
– MPX 26000
– MPX 26000‑100G
• 1200 W AC/DC
– MPX 26000‑50S
3Y power supply LED behavior
© 1999–2023 Cloud Soware Group, Inc. All rights reserved. 8
