Hardware health attributes for the MPX 16000 platform
December 6, 2022
The following table lists the recommended ranges for the health attributes on the MPX 16000 platform.
Run the ipmitool sdr list command from the shell. This command lists the sensory parameters
data in detail.
Run the stat system -detail command from the CLI. This command lists a subset of the param‑
eters.
Health Attribute (shell) Health Attribute (CLI) Recommended Range
CPU1 Temp CPU 0 Temperature (Celsius) 10–95
CPU2 Temp CPU 1 Temperature (Celsius) 10–95
PCH Temp Temperature 1 (Celsius) 10–85
System Temp Internal Temperature
(Celsius)
10–80
Peripheral Temp Temperature 0 (Celsius) 10–80
Fan 1 CPU Fan 0 Speed (RPM) 1260–8260
Fan 2 CPU Fan 1 Speed (RPM) 1260–8260
Fan 3 System Fan Speed (RPM) 1260–8260
Fan 4 System Fan 1 Speed (RPM) 1260–8260
Fan 5 System Fan 2 Speed (RPM) 1260–8260
Fan 6 Fan 0 Speed (RPM) 1260–8260
12V +12.0 V Supply Voltage 11.330–12.520
5VCC +5.0 V Supply Voltage 4.713–5.217
3.3VCC Main 3.3 V Supply Voltage 3.134–3.464
VBAT Battery Voltage (Volts) 2.591–3.464
Vcpu1VCCIN CPU 0 Core Voltage (Volts) 1.616–2.016
Vcpu2VCCIN CPU 1 Core Voltage (Volts) 1.616–2.016
Vcpu1VDDQABCD Voltage 0 (Volts) 1.096–1.344
Vcpu1VDDQEFGH Voltage 1 (Volts) 1.096–1.344
Vcpu2VDDQABCD Voltage 2 (Volts) 1.096–1.344
© 1999–2023 Cloud Soware Group, Inc. All rights reserved. 183
