BRAKES
C5FP0ELD
HANDBRAKE (Adjustment)
Adjustment
Lift and chock the vehicle.
Remove:
- The rear cover (8)
- The nut (9).
- The handbrake trim (6).
- The gear lever gaiter (5).
- The front cover (3).
- The screws (1).
Disconnect the connectors of the following components:
- The cigar lighter (2).
- The electric window buttons (4).
Remove the central console (7).
WARNING: Check that the brake cables are correctly
routed under the vehicle.
Slacken the handbrake lever.
Press gently on the brake pedal (Then repeat the ope-
ration 3 times).
Pull vigorously on the handbrake lever 4 or 5 times.
C3
