16
Instruments
Operation indicator lamps
If one of the following indicator lamps comes on, this confirms that the corresponding system has come into operation.
It may be accompanied by an audible signal and a message in the screen.
Left-hand direction
indicator
flashing with buzzer. The lighting stalk has been pushed
down.
Right-hand
direction indicator
flashing with buzzer. The lighting stalk has been pushed
up.
Sidelamps fixed. The lighting stalk is in the
"Sidelamps" position.
Dipped beam
headlamps
fixed. The lighting stalk is in the "Dipped
beam headlamps" position.
Main beam
headlamps
fixed. The lighting stalk has been pulled
towards you.
Pull the stalk to return to dipped beam headlamps.
For more information on the Lighting control stalk, refer to the corresponding section.
Warning / indicator lamp State Cause Action / Observations
