In the event of a breakdown
B618_en_Chap08_En-cas-de-panne_ed01-2016
Dashboard fuses
The 2 fuseboxes are placed in the lower
dashboard, below the steering wheel.
Fuse
N°
Rating
(A)
Functions
F29 - Not used.
F30 30 Heated rear screen.
F31 10 Heated mirrors.
F32 - Not used.
F33 40 Front electric windows.
F34 40 Rear electric windows.
F35 30 Heated front seats.
F36 - Not used.
F37 - Not used.
F38 - Not used.
F39 - Not used.
F40 - Not used.
Access to the fuses
F Unclip the cover by pulling at top left, then
right.
Upper fusebox
