Average current consumption
System User Guide - 03.12.14
4. APPENDIX
Wintax Channel Consumer Current (A)
I_INJ Injectors ˂ 10
I_COIL Coil Packs ˂ 9
I_HB Throttle body ˂ 1
I_EV_AUX VVT + WG solenoid valves ~3
I_ECU Engine Control Unit 1,1
I_DDU DDU Dashboard 1,4
I_LAMBDA Lambda sensor < 1,5
I_GMV1 Radiator fan 1 ~11
I_GMV2 Radiator fan 2 ~11
I_PULS Heater 7
I_PESS Low pressure fuel pump 7,5
I_PHYD1 Hydraulic pump 8
I_PHYD2 Hydraulic pump 6
I_PHARE High beam 10
I_CODE Low beam 9
I_STOP Stop light 4,5
I_VIRAGE Lamp pod: exterior 6,5
I_POINTE Lamp pod: interior 6,5
I_ESG Wiper motor ~3
I_EV_GBOX Isolation solenoid valve 2,5
I_EV_GBOX Clutch solenoid valve 1,5
I_EV_GBOX UP solenoid valve 1,3
I_EV_GBOX
DOWN solenoid valve
(including isolation + clutch)
5,3
