BRK outputs equivalence
System User Guide - 03.12.14
4. APPENDIX
BRK HIGH BRK LOW
Hexa value
Output cut
Hexa value
Output cut
1 Right radiator fan 1 Alternator
2 Left radiator fan 8 Tripmeter
4 Windscreen wipers 10 Scam & Smot
8 Hydraulic pump 20 Right blinker
10 VVT valve 40 Left blinker
20 Gearbox valve 80 Front position lights
40 Heater 200 Revering light
80 Low beam 400 Bosch module
100 Front fog lights 800 Rear fog light
200
Lamp pod: interior
1000 Rear position lights
400
Lamp pod: exterior
2000 Infra-red beacon
800 High beam 4000 Map light
1000 Horn 8000 Lambda sensor
2000 Hydraulic pump
4000 Low pressure fuel pump
8000 Supplementary feeds
10000 Stop lights
20000 DDU display
40000 Radio
