Removing a wheel
Parking the vehicle
Immobilise the vehicle where it does not
block traffic: the ground must be level,
stable and not slippery.
Apply the parking brake unless it has
been programmed to automatic mode,
switch off the ignition and engage first
gear * to block the wheels.
Check that the braking warning lamp
and the P warning lamp in the parking
brake control lever come on.
The occupants must get out of the
vehicle and wait where they are safe.
Never go underneath a vehicle raised
using a jack; use an axle stand.
List of operations
Depending on equipment, remove the cover from from each of bolts using the tool 3 or remove
the hub cap using tool 4 .
Fit the security socket 5 on the wheelbrace 1 to slacken the security bolt (if fitted).
Slacken the other bolts (no more than a 1/4 turn) using the wheelbrace 1 only.
* Position R for an electronic gearbox; P for an
automatic gearbox.
