319
AXLES
SUSPENSION
STEERING
REAR AXLE
SAXO
- All
T
ypes
(1)
Rear axle.
(2)
Damper.
(5)
Rear suspension arm.
(7)
Rear brake drum.
(9)
T
orsion bar
.
The antiroll bar is located inside the tube of the rear axle.
Tightening torques m.daN.
(3)
Damper upper fixing screw
10 ±
1
(4)
Damper lower fixing screw
10 ±
1
(6)
Stub nut
20 ±
1
(8)
Rear axle fixing bolt
8.7 ±
1
B3DP02ND
322
324
