[SMB-14E]
— 11-1 —
MAINTENANCE AND
TROUBLESHOOTING
11
11. MAINTENANCE AND TROUBLESHOOTING
1) Maintenance Inspection
(1) Periodical Inspection
For using ABSODEX long time, make a periodical inspection (once or twice a year). Turn
off power for inspection except for the items 4, 6 and 8 which require to be inspected with
power ON.
Table 11.1 Periodical Inspection
Inspection Item Inspection Method Countermeasures
1. Dust inside the driver Inspect internal visually. Clean internal of the driver.
2. Loose terminal screw and
connectors
Check that the screws and
connectors are not loose.
Re-tighten screws and connectors.
3. Discoloration by heat, and
damage, and liquid leak from
the capacitor
Visually inspect internal. Replace parts or request CKD to
repair.
4. Check if the fan operates
correctly.
Check the fan visually or
by hearing.
Replace the faulty part.
5. Clogging in the fan exhaust
vent.
Check the exhaust vent
visually.
Clean.
6. Abnormal noise from actuator
and brake part.
Confirm by hearing. Replace parts or request CKD to
repair.
7. Cuts and crack in cable. Check the cable visually. Replace faulty cable.
8. Power voltage Confirm the supply voltage
with a tester.
Check the power supply system to
supply power within the specified
voltage range.
9. Compressed air pressure for
brake (with pneumatic brake)
Check the air pressure
gauge.
Adjust the regulator. (0.5MPa)
10. Fouled air filter for compressed
air (with pneumatic brake)
Inspect the filter visually. Follow the air equipment
maintenance manual.
11. Brake condition (with brake) Inspect the brake
manually.
Replace brake parts or request
CKD to repair.
12. Blown fuse. Check the fuse visually. Replace the faulty part.
(2) Maintenance Parts List
Table 11.2 Maintenance Parts List
Parts Name Model Maker Remarks
FGBO (10A, 250VAC) FUJI TERMINAL Standard model
1. Fuse
19195 (10A, 250VAC) WICKMAN
Models complying with
EU directives (-K)
2. SELEX valve AX-0002 CKD
3. Cooling fan
AX-0003 (Note)
(2408NL-04W-B20)
NMB
Note: The AX-0003 is the NMB made fan with the connector added by CKD.
To Next Page
