CKD GX8275D User Manual

2
Coefcients for model selection in GX8200 Series
Model No. GX8203D GX8204D GX8208D GX8215D GX8222D GX8237D GX8255D GX8265D GX8275D GX8295D
Processing air ow 0.32 0.70 1.10 2.80 4.60 7.60 8.80 10.70 14.90 18.40
Model No. GX8203D GX8204D GX8208D GX8215D GX8222D GX8237D GX8255D GX8265D GX8275D GX8295D
Maximum coefcient 1.40 1.70 2.59 1.53 1.65 1.41 1.62 1.44 1.51 1.67
Model No. GX8203D GX8204D GX8208D GX8215D GX8222D GX8237D GX8255D GX8265D GX8275D GX8295D
Processing air ow 0.44 0.97 2.31 3.48 6.16 8.71 11.54 12.55 18.30 25.39
Standard air ow (m
3
/min)
Model No. GX8203D GX8204D GX8208D GX8215D GX8222D GX8237D GX8255D GX8265D GX8275D GX8295D
Inlet air temperature
(
°
C)
35 1.00 1.00 1.52 0.90 0.97 0.83 0.95 0.85 0.89 1.00
40 0.98 1.00 1.20 0.91 0.97 0.87 0.95 0.88 0.91 1.00
45 0.98 1.00 1.10 0.97 0.98 0.94 0.95 0.95 0.96 1.00
Correction coefcient for each model (Applicable to inlet temperatures of, 35°C, 40°C and 45°C)
Inlet air temperature (°C) 35 40 45 50 55 60 70 80
Pressure dew point (
°
C) 5 10 15 5 10 15 5 10 15 5 10 15 5 10 15 5 10 15 5 10 15 5 10 15
Ambient temperature
(
°
C)
30 1.16 1.42 1.70 1.03 1.35 1.62 0.89 1.21 1.46 0.78 1.08 1.29 0.69 0.92 1.10 0.62 0.80 0.94 0.53 0.68 0.82 0.48 0.63 0.77
32 1.12 1.38 1.66 0.98 1.29 1.55 0.85 1.16 1.40 0.76 1.03 1.25 0.65 0.87 1.03 0.60 0.75 0.89 0.50 0.64 0.78 0.45 0.60 0.73
35 1.10 1.34 1.62 0.94 1.25 1.50 0.82 1.13 1.35 0.73 1.00 1.21 0.62 0.82 0.98 0.57 0.70 0.86 0.47 0.60 0.74 0.41 0.55 0.69
40 1.05 1.25 1.52 0.85 1.07 1.22 0.66 0.86 1.02 0.55 0.75 0.91 0.48 0.62 0.75 0.44 0.56 0.66 0.37 0.46 0.55 0.33 0.42 0.51
43 0.84 1.02 1.29 0.63 0.82 1.03 0.50 0.66 0.84 0.42 0.59 0.74 0.38 0.51 0.63 0.35 0.46 0.56 0.30 0.38 0.47 0.26 0.32 0.40
Temperature correction coefcient
Air pressure (MPa) 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Correction coefcient 0.67 0.73 0.80 0.87 0.93 1.00 1.07 1.13 1.2
Pressure correction coefcient
Maximum coefcient (Maximum value of ( × ))
Flow rate with Inlet temperature 35°C, Ambient temperature 32°C, Air pressure 0.7 MPa, Pressure dew point 10°C (m
3
/min)
Please select model that has value of used air content calculation result below.
Processing air ow of dryer= Standard air ow × [ Correction coefcient for each model × Temperature correction coefcient (In air
temperature
•
Pressure dew point
•
Ambient temperature)] × Pressure correction coefcient
Note: ( Correction coefcient for each model × Temperature correction coefcient)’s maximum value is Maximum
coefcient.
In case ( Correction coefcient for each model × Temperature correction coefcient) exceeds this value, please
calculate by Maximum coefcient.
<Calculation example>
For GX8215D with Inlet temperature 35°C • Ambient temperature 32°C • Outlet pressure dew point 10°C • Air pressure 0.7MPa,
calculate process amount:
( Correction coefcient for each model × Temperature correction coefcient) = 0.9 × 1.38 = 1.242
Since it does not surpass GX8215D’s maximum coefcient of 1.53, dryer processing air ow is:
2.80 (Standard processing air ow) × 1.242 × 1.0 = 3.47 m
3
/min
GX8200 Series
Selection guide
