CKD PPX Series User Manual

JIS symbol
Digital pressure sensor
PPX Series
Specifications
Descriptions
Standard type High function type
For low pressure
PPX-R01*
For high pressure
PPX-R10*
For low pressure
PPX-R01*H
For high pressure
PPX-R10*H
Kind of pressure Gauge pressure
Rated pressure -100.0 to +100.0kPa -0.100 to +1.000MPa -100.0 to +100.0kPa -0.100 to +1.000MPa
Set pressure -101.0 to +101.0kPa -0.101 to +1.010MPa -101.0 to +101.0kPa -0.101 to +1.010MPa
Proof pressure 500kPa 1.5MPa 500kPa 1.5MPa
Applicable uid Air/non-corrosive gas
Power supply voltage 12 to 24VDC ±10% ripple P-P 10% or less
Power consumption
Normal: 720mW or less (power consumption 30mA or less at 24V power supply voltage)
ECO mode: 480mW or less at STD (power consumption 20mA or less at power supply voltage 24V), 360mW or less at FULL (power consumption 15mA or less at power supply voltage 24V)
Comparison output
(comparison output 1/
comparison output 2)
<NPN output type>
NPN transistor/open collector
• Max. inrush current: 100mA
• Applied voltage: 30VDC or less (comparison output–0V interval)
• Residual voltage: 2V or less (at inrush current 100mA)
<PNP output type>
PNP transistor/open collector
• Max. outow current: 100mA
• Applied voltage: 30VDC or less (comparison output between – and +)
• Residual voltage: 2V or less (at output current 100mA)
Output operation Select NO/NC with the key operation
Output mode EASY MODE/hysteresis mode/window comparator mode
Hysteresis Min.1 digit (variable)
Repeatability ±0.1% F.S. (Within ±2 digits) ±0.2% F.S. (Within ±2 digits) ±0.1% F.S. (Within ±2 digits) ±0.2% F.S. (Within ±2 digits)
Response time 2.5ms, 5ms, 10ms, 25ms, 50ms, 100ms, 250ms, 500ms, 1000ms, 5000ms select by the key operation
Short circuit protection Equipped
External input
(auto reference/remote
zero adjusting)
<NPN output type>
ON voltage: 0.4VDC or less
OFF voltage: 5 to 30VDC or release
Input impedance: approx. 10kΩ
Input time: 1ms and over
<PNP output type>
ON Voltage: 5V to
+
VDC
OFF voltage: 0.6VDC or less or release
Input impedance: approx. 10kΩ
Input time: 1ms and over
Analog voltage output
Output voltage: 1 to 5V
Zero point: Within 3V ±5% F.S.
Span: Within 4V ±5% F.S.
Linearity: Within ±1% F.S.
Output impedance: approx. 1kΩ
Output voltage: 0.6 to 5V
Zero point: Within 1V ±5% F.S.
Span: Within 4.4V ±5% F.S.
Linearity: Within ±1% F.S.
Output impedance: approx. 1kΩ
Analog current output
Output current: 4 to 20mA
Zero point: Within 12mA ±5% F.S.
Span: Within 16mA ±5% F.S.
Linearity: Within ±1% F.S.
Load resistance: 250Ω (max.)
Output voltage: 2.4 to 20mA
Zero point: Within 4mA ±5% F.S.
Span: Within 17.6mA ±5% F.S.
Linearity: Within ±1% F.S.
Load resistance: 250Ω (max.)
Display 4-digit + 4-digit tri-color LCD display (display update cycle: 250ms, 500ms, 1000ms, select with key operations)
Display pressure range -101.0 to +101.0kPa -0.101 to +1.010MPa -101.0 to +101.0kPa -0.101 to +1.010MPa
Indicator light
Orange LED
(Comparison output 1 operational indicator light, comparison output 2 operational indicator light: comparison output ON lighting)
Orange LED
(Comparison output 1 operational indicator light: comparison output ON lighting, analog voltage output operational indicator light: Lighting when setting)
Environmental
resistance
Degree of protection IP40 (IEC)
Ambient temperature -10 to + 50°C , at store: -10 to + 60°C
Ambient humidity 35 to 85% RH (no dew condensation, freezing), store: 35 to 85% RH
Withstand voltage 1000VAC for one minute applied to all charged sections/between cases
Insulation resistance 50MΩ and over with 500VDC mega applied to all charged sections/between cases
Vibration resistance Durability 10 to 500Hz double amplitude 3mm 2 hours each in XYZ directions (when mounted on panel: durability 10 to 150Hz double amplitude width 0.75mm 2 hours each in XYZ directions)
Shock resistance Durability 100m/S
2
(approx. 10 G) 3 times each in XYZ directions
Temperature characteristics (+ 20°C reference) Within ±0.5% F.S. Within ±1% F.S. Within ±0.5% F.S. Within ±1% F.S.
Port size
Note 1 M5 female thread + R (PT) 1/8 male thread
Material
Case: PBT (with glass ber), LCD display part: acrylic, pressure port: SUS303, mounting screw part: brass (nickel coat), switch part: silicon rubber
Connection Connector
Wiring length Up to 100m permissible with 0.3mm
2
or larger cable (less than 30m when CE Mark-compliant)
Unit change Compatible only with export models (-KA) (MPa, kPa, kgf/cm
2
, bar, psi, mmHg, inchHg)
Weight Product weight: approx. 40g, weight including package: 130g
Accessory
Note 2
PPX-C2 (2m cable with connector): 1 pc.
Unit seal label (KA with unit change): MPa, kPa.kgf/cm
2
, bar, psi, mmHg, inchHg
Note 1: See Table 1 on the next page for export use.
Note 2: For (- J), connector cable is not attached.
1
