2.4 Attachment parts / machine body
66258
2.4 Attachment parts / machine body
107692
2.4.1 Access to the workplace and mainte-
nance areas
The operator's workplace / driver's seat (1) is in the
machine cab. The operating elements in the workplace
are used to start or shut down the machine.
The machine maintenance areas allow maintenance
or adjustment work to be performed.
– Enter the workplace in the cab via the front
ladder (2) and via the maintenance area at the
left-hand operator's platform (3).
12
39598
1
Danger!
Danger of falling!
Death or serious injuries!
– Only enter areas that are designated as
workplaces or maintenance areas
and are secured by railings or similar.
– Other areas must be secured by addi-
tional rails / safety measures before they
are entered.
13
LEXION 560-510
39599
14
LEXION 560 Terra-Trac
39601
2
3
2
3
