1.4.4 RHB MEDION 340 - 310 - 299 216.0
Torque settings
Wheel bolts
Tightening torques for drive axle and rear axle / rear drive axle wheel bolts
Drive axle Wheel bolts M 22 x 1.5 x 65 – 10.9
and thrust plate nuts H 22 DIN 74361-10 = 700 Nm
Attention!
Thrust plate nuts with Dacromet coating (silvery grey) must only
be torqued to 700 Nm.
Rear axle Wheel bolts M 18 x 1.5 x 30 DIN 961-8.8
and circlips 20 x 1.75 DIN 471 = 325 Nm
Wheel bolts M 18 x 1.5 x 40 DIN 961-8.8
and spring washers C 18.5 DIN 74361
(special lock washers) = 325 Nm
Wheel bolts M 18 x 1.5 x 35 DIN 961-8.8
and spring washers C 18.5 DIN 74361
(special lock washers) = 325 Nm
Rear drive axle Wheel bolts M 22 x 1.5 x 45 DIN 961-8.8
and spring washers C 22.5 DIN 74361
(special lock washer) = 520 Nm
