F I L T E R A G + S e r i e s F i l t e r
Installation Operation Maintenance Manual
FILTERAG+ WS Rev 1 Page 14 of 16
1 1 . 2 E N G I N E E R I N G D A T A
11.2.1 FILTER AG + Series Filters CAP1054 to CAP 1465
Model
CAP1054 CAP1248 CAP1354 CAP1465
Valve WS1 WS1 WS1 WS1
Filter Vessel 1054 1248 1354 1465
Parameter Unit
Height of Filter Mm 1607 1458 1601 1984
Diameter of
Filter
Mm 254 305 331 356
Height of Valve mm 170 170 170 170
Filter Inlet
Conn.
Inches
BSPM
1 1 1 1
Filter Outlet
Conn.
Inches
BSPM
1 1 1 1
Drain Conn. Inches
BSPM
3/4 3/4 3/4 ¾
Qty of Gravel Bags 0.5 0.5 0.75 1.5
Qty of
FILTERAG+
Bags 1 1.5 2 2.5
Electrical Power Watts 1.2 1.2 1.2 1.2
PRESSURE 1.7 Bar MAXIMUM OPERATING TEMPERATURE 45.0C
HEADROOM - Allow 100 mm greater than overall height.
11.2.2 FILTER AG + Series Filters CAP1665 to CAP2469
Model
CAP1665 CAP1865 CAP2160 CAP2469
Valve WS1.5 WS1.5 WS2 WS2
Filter Vessel 1665 1865 2160 2469
Parameter Unit
Height of Filter Mm 1988 2088 2098 2348
Diameter of
Filter
Mm 407 460 534 610
Height of Valve mm 170 170 170 170
Filter Inlet
Conn.
Inches
BSPM
1 1 1.5 1.5
Filter Outlet
Conn.
Inches
BSPM
1 1 1.5 1.5
Drain Conn. Inches
BSPM
1 1 1.5 1.5
Qty of Gravel Bags 1.5 2 3 5
Qty of Sand Bags 4 5 6 8
Electrical Power Watts 1.2 1.2 1.2 1.2
PRESSURE 1.7 Bar MAXIMUM OPERATING TEMPERATURE 45.0C
HEADROOM - Allow 100 mm greater than overall height.
