Clarion ADB340MP Service Manual

ADB340MP
ADB341MP
- 17 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R789 653-0429-56 100KOHM 1/16W
R790 653-0429-56 100KOHM 1/16W
R791 653-0429-53 10OHM 1/16W
R792 653-0429-56 100KOHM 1/16W
R793 653-0429-51 1KOHM 1/16W
R794 653-0429-51 1KOHM 1/16W
R795 653-0429-56 100KOHM 1/16W
R796 653-0429-56 100KOHM 1/16W
R798 653-0429-56 100KOHM 1/16W
R799 653-0429-86 56KOHM 1/16W
R801 653-0429-24 0OHM 1/8W
R802 653-0429-23 0OHM 1/16W
TH651 653-0429-87 PTC-B59975-C120-
A54
PWB 653-0429-88 PWB(WITHOUT
COMPONENT)
Display PWB(B3) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C901 653-0428-58 1000PF 50V
C902 653-0428-67 0.1UF 16V
C903 653-0428-60 0.047UF 16V
C904 653-0428-60 0.047UF 16V
C905 653-0428-60 0.047UF 16V
D902 653-0429-92 BZX84-C5V1
D905 653-0429-93 UDZS8.2B
D912 653-0429-94 NSPW300BS-BR,
BS
D913 653-0429-94 NSPW300BS-BR,
BS
D914 653-0429-95 HPY1105W-TR-CT
H901 653-0429-96 LCD
IC901 653-0429-97 LC75878W
P901 653-0429-98 SOCKET(MAIN)
PL901 653-0429-99 PL ASSY 171
PL902 653-0429-99 PL ASSY 171
PL903 653-0429-99 PL ASSY 171
PL904 653-0429-99 PL ASSY 171
PL905 653-0429-99 PL ASSY 171
PL906 653-0429-99 PL ASSY 171
R901 653-0429-74 1KOHM 1/10W
R902 653-0429-74 1KOHM 1/10W
R903 653-0429-74 1KOHM 1/10W
R904 653-0429-74 1KOHM 1/10W
R905 653-0429-65 47KOHM 1/16W
R906 653-0429-56 100KOHM 1/16W
R907 653-0430-01 1.8KOHM 1/16W
R908 653-0429-74 1KOHM 1/10W
R911 653-0430-02 330OHM 1/10W
R913 653-0430-02 330OHM 1/10W
R919 653-0430-03 3.9KOHM 1/10W
R941 653-0430-04 1.2KOHM 1/16W
R942 653-0430-04 1.2KOHM 1/16W
R943 653-0430-01 1.8KOHM 1/16W
R944 653-0430-05 2.7KOHM 1/16W
R945 653-0429-52 4.7KOHM 1/16W
R946 653-0429-71 8.2KOHM 1/16W
R947 653-0429-79 18KOHM 1/16W
R948 653-0430-04 1.2KOHM 1/16W
R949 653-0430-04 1.2KOHM 1/16W
R950 653-0430-01 1.8KOHM 1/16W
R951 653-0430-05 2.7KOHM 1/16W
R952 653-0429-52 4.7KOHM 1/16W
R953 653-0429-71 8.2KOHM 1/16W
R954 653-0429-51 1KOHM 1/16W
R955 653-0429-51 1KOHM 1/16W
R956 653-0429-51 1KOHM 1/16W
R957 653-0429-51 1KOHM 1/16W
SW901 653-0430-06 VOLUME
SW902 653-0430-06 VOLUME
SW903 653-0430-07 DTSM-31S-T/R-CT
SW904 653-0430-07 DTSM-31S-T/R-CT
SW905 653-0430-07 DTSM-31S-T/R-CT
SW906 653-0430-07 DTSM-31S-T/R-CT
SW907 653-0430-07 DTSM-31S-T/R-CT
SW908 653-0430-07 DTSM-31S-T/R-CT
SW909 653-0430-07 DTSM-31S-T/R-CT
SW910 653-0430-07 DTSM-31S-T/R-CT
SW911 653-0430-07 DTSM-31S-T/R-CT
SW912 653-0430-07 DTSM-31S-T/R-CT
SW913 653-0430-07 DTSM-31S-T/R-CT
SW914 653-0430-07 DTSM-31S-T/R-CT
SW915 653-0430-07 DTSM-31S-T/R-CT
SW916 653-0430-07 DTSM-31S-T/R-CT
SW917 653-0430-07 DTSM-31S-T/R-CT
SW918 653-0430-07 DTSM-31S-T/R-CT
SW919 653-0430-08 SOT-152HST-CT
PWB 653-0430-09 PWB(WITHOUT
COMPONENT)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
CA01 653-0430-16 100uF 4V
CA02 653-0430-17 6800pF 50V
CA03 653-0428-74 1uF 10V
CA04 653-0428-66 0.1uF 16V
CA05 653-0428-66 0.1uF 16V
CA06 653-0430-18 4pF 50V
CA07 653-0430-19 56pF 50V
CA08 653-0428-67 0.1uF 16V
CA21 653-0428-67 0.1uF 16V
CA22 653-0428-67 0.1uF 16V
CA23 653-0430-20 47pF 50V
CA24 653-0430-21 0.015uF 25V
CA26 653-0428-59 0.01uF 50V
CA27 653-0430-22 2700pF 50V
CA28 653-0428-59 0.01uF 50V
CA29 653-0428-67 0.1uF 16V
CA31 653-0428-79 333 B
CA32 653-0428-79 333 B
CA33 653-0428-60 0.047uF 16V
CA34 653-0428-69 470pF 50V
CA35 653-0428-69 470pF 50V
CA36 653-0428-60 0.047uF 16V
CA37 653-0428-60 0.047uF 16V
CA38 653-0428-60 0.047uF 16V
CA39 653-0428-60 0.047uF 16V
CA40 653-0428-67 0.1uF 16V
CA41 653-0428-67 0.1uF 16V
CA44 653-0430-16 100uF 4V
CA45 653-0430-16 100uF 4V
CA46 653-0428-67 0.1uF 16V
CA47 653-0430-16 100uF 4V
CA48 653-0428-67 0.1uF 16V
CA50 653-0428-90 2200pF 50V
CA51 653-0428-90 2200pF 50V
CA61 653-0430-23 100uF 10V
CA62 653-0428-67 0.1uF 16V
CA68 653-0428-67 0.1uF 16V
CA72 653-0428-67 0.1uF 16V
CA73 653-0428-74 1uF 10V
CA74 653-0430-24 47uF 6.3V
CA75 653-0428-67 0.1uF 16V
CA77 653-0430-25 100uF 10V
CB02 653-0428-67 0.1uF 16V
CB03 653-0430-26 47uF 4V
CB04 653-0428-67 0.1uF 16V
CB05 653-0430-26 47uF 4V
CB06 653-0430-26 47uF 4V
CB07 653-0430-26 47uF 4V
CB08 653-0428-67 0.1uF 16V
CB09 653-0428-67 0.1uF 16V
CB10 653-0430-27 0.33uF 10V
CB11 653-0428-67 0.1uF 16V
CB14 653-0428-67 0.1uF 16V
CB16 653-0428-76 220pF 50V
CB51 653-0430-26 47uF 4V
CB52 653-0428-74 1uF 10V
CB53 653-0428-59 0.01uF 50V
CB54 653-0428-74 1uF 10V
CB55 653-0430-26 47uF 4V
CB56 653-0428-74 1uF 10V
CB57 653-0428-59 0.01uF 50V
CB58 653-0428-74 1uF 10V
CB59 653-0430-26 47uF 4V
CB60 653-0428-74 1uF 10V
CB61 653-0428-59 0.01uF 50V
CB62 653-0428-74 1uF 10V
Servo PWB(B4) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Sub PWB(B2) section
DC02 653-0429-95 HPY1105W-TR-CT
DC03 653-0429-95 HPY1105W-TR-CT
DC04 653-0429-95 HPY1105W-TR-CT
DC05 653-0429-95 HPY1105W-TR-CT
DC06 653-0429-95 HPY1105W-TR-CT
PC01 653-0430-60 SOCKET(MAIN)
RC01 653-0429-75 470OHM 1/10W
RC02 653-0430-61 150OHM 1/10W
RC03 653-0430-61 150OHM 1/10W
RC04 653-0430-61 150OHM 1/10W
SWC01 653-0430-62 SKQCAC-260G
PWB 653-0430-63 PWB(WITHOUT
COMPONENT)
