Clarion ADB340MP Service Manual

ADB340MP
ADB341MP
- 18 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
DA01 653-0430-29 DAP202KT146
FB01 653-0430-30 RTSV16.93MG
ICA01 653-0430-31 TA2157FN-CT
ICA02 653-0430-32 TC94A14FA-CT
ICA03 653-0430-33 BA5983FM-CT
ICA04 653-0430-34 BA033FP-CT
ICB01 653-0430-35 TC94A20F-010-CT
ICB03 653-0430-36 TAR5S33-CT
ICB04 653-0430-37 TAR5S25-CT
ICB05 653-0430-37 TAR5S25-CT
JA23 653-0429-23 0ohm 1/16W
JA24 653-0430-38 0ohm 1/10W
JA32 653-0429-23 0ohm 1/16W
JB01 653-0429-23 0ohm 1/16W
LA01 653-0429-28 FCM1608K-301T03
LA21 653-0429-23 0ohm 1/16W
LA22 653-0429-28 FCM1608K-301T03
LB01 653-0429-28 FCM1608K-301T03
LB03 653-0429-28 FCM1608K-301T03
LB31 653-0429-23 0ohm 1/16W
NA01 653-0430-39 FLAT WIRE(25P)
PA01 653-0430-40 15P
PA02 653-0430-41 8P
QA01 653-0430-42 2SB815T-B6
QA02 653-0430-43 2SD2537T-V
RA01 653-0430-44 91ohm 1/16W
RA02 653-0430-45 10ohm 1/10W
RA03 653-0430-46 820ohm 1/16W
RA04 653-0429-66 22k ohm 1/16W
RA05 653-0430-47 120k ohm 1/16W
RA06 653-0430-47 120k ohm 1/16W
RA07 653-0429-56 100k ohm 1/16W
RA08 653-0429-56 100k ohm 1/16W
RA09 653-0429-73 39k ohm 1/16W
RA10 653-0429-57 100ohm 1/16W
RA11 653-0429-50 10k ohm 1/16W
RA12 653-0429-82 2.2k ohm 1/16W
RA13 653-0429-51 1k ohm 1/16W
RA14 653-0429-66 22k ohm 1/16W
RA21 653-0429-50 10k ohm 1/16W
RA22 653-0429-79 18k ohm 1/16W
RA23 653-0429-54 5.6k ohm 1/16W
RA24 653-0429-65 47k ohm 1/16W
RA25 653-0430-48 220k ohm 1/16W
RA26 653-0430-49 2.2Mohm 1/16W
RA27 653-0430-50 15k ohm 1/16W
RA28 653-0429-50 10k ohm 1/16W
RA29 653-0429-23 0ohm 1/16W
RA30 653-0429-23 0ohm 1/16W
RA31 653-0429-23 0ohm 1/16W
RA32 653-0429-23 0ohm 1/16W
RA33 653-0429-83 3.3k ohm 1/16W
RA37 653-0429-82 2.2k ohm 1/16W
RA41 653-0429-23 0ohm 1/16W
RA65 653-0430-50 15k ohm 1/16W
RA66 653-0430-50 15k ohm 1/16W
RA71 653-0430-51 82ohm 1/16W
RA72 653-0430-52 560ohm 1/16W
RA94 653-0429-23 0ohm 1/16W
RA95 653-0429-23 0ohm 1/16W
RB02 653-0430-53 MNR14E0ABJ184-
CT
RB03 653-0430-54 MNR14E0ABJ104-
CT
RB04 653-0430-53 MNR14E0ABJ184-
CT
RB05 653-0430-55 180k ohm 1/16W
RB06 653-0429-56 100k ohm 1/16W
RB07 653-0429-51 1k ohm 1/16W
RB08 653-0429-51 1k ohm 1/16W
RB09 653-0429-70 330ohm 1/16W
RB10 653-0429-70 330ohm 1/16W
RB11 653-0430-56 1M ohm 1/16W
RB12 653-0430-57 1.5k ohm 1/16W
RB13 653-0430-58 100k ohm 1/10W
RB14 653-0429-57 100ohm 1/16W
RB31 653-0430-54 MNR14E0ABJ104-
CT
RB32 653-0430-54 MNR14E0ABJ104-
CT
RB33 653-0430-54 MNR14E0ABJ104-
CT
PWB 653-0430-59 PWB(WITHOUT
COMPONENT)
Switch-A PWB(B5) section (CD mechanism)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
SW1 653-0431-11 INSW
SW2 653-0431-11 12CM
PWB 653-0431-20 PWB(WITHOUT
COMPONENT)
REF No. PART No. DESCRIPTION
Switch-B PWB(B6) section (CD mechanism)
SW3 653-0431-11 INNER
PWB 653-0431-21 PWB(WITHOUT
COMPONENT)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Reel PWB(B7) section (Cassette tape mechanism)
Q1 653-0431-43 PH SENSOR
S1 653-0431-41 CA-IN
S2 653-0431-44 ST-BY
S3 653-0431-40 MODE
PWB 653-0431-39 PWB(WITHOUT
COMPONENT)
