OWNER’S MANUAL
3
CONNECTIONS FOR POWER AND SPEAKERS
The rear panel of the APX200.2M contains power and speaker connections as
shown below.
Figure 2
1. Left Speaker Output
2. Right Speaker Output
3. Remote Turn-on Input
4. Ground Input
5. Battery + 12V Input
6. 25 Amp Fuse
