2.
CONTROLS / LES COMMANDES / REGLER / CONTROLLI
REGELAARS / CONTROLES / KONTROLLER / CONTROLOS
3. NOMENCLATURE
Note:
• Be sure to read this chapter referring to the front diagrams of chapter “2. CONTROLS” on page 5 (unfold).
Names of the Buttons and their Functions
Main unit / Appareil principal / Hauptgerät / Apparecchio principale
Hoofdtoestel / Unidad principal / Huvudenhet / Unidade principal
Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.
Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre.
Hinweis: Bitte diese Seite ausfalten und beim Lesen der einzelnen Kapital die Frontdiagramme beachten.
Nota: Assicurarsi di aprire questa pagina e fare riferimento a questi diagrammi quando si legge ciascun capitolo.
Opmerking: Vouw deze pagina uit en zie tevens de afbeeldingen van het voorpaneel tijdens het doorlezen van de volgende hoofdstukken.
Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas.
Observera: Vik ut denna sida för att kunna se figurerna över bilstereons framsida medan du läser de olika kapitlen.
Nota: Certifique-se de abrir esta página e consulte os diagramas frontais conforme realiza a leitura de cada capítulo.
[ ]
[ ]
[
ROTARY
]
[
RELEASE
]
[
CD SLOT
]
[
Z
]
[
A-M
]
[
SRC
]
[
D
]
[
RPT
]
[
DIRECT
]
[
RDM
]
[
SCN
]
[
TA
]
[
T
]
[
BND
]
[ ]
[
UP
]
[
DN
]
[
SENSOR
]
[ ]
[RELEASE] button
• Press the [RELEASE] button to unlock the
DCP.
[ROTARY] knob
• Adjust the volume by turning the knob
clockwise or counterclockwise.
• Use the knob to perform various settings.
[CD SLOT]
• CD insertion slot.
[Z] button
• Use the button to select one of the three types
of sound characteristics already stored in
memory. (Z-Enhancer)
[Q] button
• Ejects a CD when it is loaded into the unit.
[DIRECT] button
• Stores a station into memory or recall it
directly while in the radio mode.
[TA] button
• Use the button to set the TA (Traffic
Announcement) standby mode.
• Long press to enter RDS mode.
[RPT] button
• Plays repeatedly while in the CD/MP3 mode.
[RDM] button
• Performs random play while in the CD/MP3
mode.
[SCN] button
• Performs scan play for 10 seconds for each
track while in the CD/MP3 mode.
[UP] button
• Play first track of next folder which contain
MP3 files.∗
∗ Key function only available after MP3 indicator
turned on.
[DN] button
• Play first track of previous folder which
contain MP3 files.∗
∗ Key function only available after MP3 indicator
turned on.
[T] button
• Switches MP3 TITLE display.
• Press and hold for 1 second to scroll display
data.
[D] button
• Switch the display indication (Main display,
clock display).
MP3 FUNCTION-DISPLAY SELECTION
• Display changes in the following order: Track
No. / Play time ➜ Folder No. / Track No. ➜
Title Display ➜ Clock Display ➜ Track No. /
Play time...
• Long press to enter adjustment mode.
[BND] button
• Switches the band, or seek tuning or manual
tuning while in the radio mode.
• Plays a first track while in the CD/MP3 mode.
• Press and hold the button to select between
CD-DA playback and MP3 playback in
multisession CD.
[SENSOR] button
• Receiver for remote control unit.
• Operating range: 30° in all directions.
[SRC] button
• Press the button to turn on the power.
Press and hold the button for 1 second or
longer to turn off the power.
• Switches the operation mode between radio
and CD/MP3 mode.
[ ] button
• Plays or pauses a CD while in the CD/MP3
mode.
• To enter various setting.
• Performs preset scan while in the radio
mode. When the button is pressed and held,
auto store is performed.
[A-M] button
• Press and hold the button for 1 second or
longer to switch the MAGNA BASS EX on/off.
• Use the button to switch to the audio mode
(bass/treble, balance/fader).
[å], [∂] buttons
• Selects a station while in the radio mode or
selects a track when listening to a CD/MP3.
• Press and hold the button for 1 second or
longer to switches the fast-forward/fast-
backward.
Display Items
LCD Screen
In extreme cold, the screen movement may slow down and the screen may darken, but this is normal.
The screen will recover when it returns to normal temperature.
