Clarion DB189RGMP Service Manual

-11-
DB188/189RMP/DB189RGMP
Switch PWB(B2) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C701 043-1841-90 0.047uF Q713 125-2027-92
TRANSISTOR
S703 013-6312-50 SWITCH
C702 043-1841-90 0.047uF Q713 125-2041-93
RT1N241M
S704 013-6312-50 SWITCH
C703 043-1841-90 0.047uF Q714 125-2027-92 TRANSISTOR S705 013-6312-50 SWITCH
C704 043-1800-90 1000pF Q714 125-2041-93 RT1N241M S706 013-6312-50 SWITCH
C705 042-0423-97 16V 10uF TAN R701 119-3311-15 1/10W 330 ohm S707 013-6312-50 SWITCH
C707 043-1841-90 0.047uF
R702 119-3931-15 1/10W 39k ohm
S709 013-6312-50 SWITCH
D702 001-4907-90 PG05GBUSU
R703 119-1041-15 1/10W 100k ohm
S710 013-6312-50 SWITCH
D705 001-4301-29 HZU5.1B2 R704 119-3921-15 1/10W 3.9k ohm S711 013-6312-50 SWITCH
D706 001-4301-29 HZU5.1B2 R709 119-4721-15 1/10W 4.7k ohm S713 013-6312-50 SWITCH
D707 001-4907-90 PG05GBUSU R715 119-1021-15 1/10W 1k ohm S714 013-6312-50 SWITCH
D708 001-4907-90 PG05GBUSU R716 119-1021-15 1/10W 1k ohm S715 013-6312-50 SWITCH
D717 001-4301-29 HZU5.1B2 R717 119-1021-15 1/10W 1k ohm S716 013-6312-50 SWITCH
D718 001-4301-41 HZU7.5B2 R718 119-1021-15 1/10W 1k ohm S717 013-6312-50 SWITCH
D720 001-4301-51 HZU10B3 R723 119-0000-05 1/10W 0 ohm JW S718 016-9901-02 VR W/SHAFT
IC701 051-6095-00 LC75857 S701 013-6312-50 SWITCH PWB 039-3208-01 PWB(WITHOUT
J701 076-0615-50 12P S702 013-6312-50 SWITCH COMPONENT)
LCD701
379-1401-41
INDICATOR(LCD)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D711 001-7114-90 LWL38G-Q1R2 D716 001-7114-90 LWL38G-Q1R2 R719 119-4711-15 1/10W 470 ohm
D712 001-7114-90 LWL38G-Q1R2 R705 119-1221-15 1/10W 1.2k ohm R720 119-4711-15 1/10W 470 ohm
D713 001-7114-90 LWL38G-Q1R2 R706 119-4711-15 1/10W 470 ohm R724 119-1221-15 1/10W 1.2k ohm
D714 001-7114-90 LWL38G-Q1R2 R713 119-4711-15 1/10W 470 ohm R725 119-4711-15 1/10W 470 ohm
D715 001-7114-90 LWL38G-Q1R2 R714 119-4711-15 1/10W 470 ohm
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D711 001-7115-90
VFA1111C-4B93B
R700 119-5611-15 1/10W 560 ohm R719 119-1011-15 1/10W 100 ohm
D712 001-7115-90
VFA1111C-4B93B
R705 119-5611-15 1/10W 560 ohm R720 119-1011-15 1/10W 100 ohm
D713 001-7115-90
VFA1111C-4B93B
R706 119-5611-15 1/10W 560 ohm R724 119-5611-15 1/10W 560 ohm
D714 001-7115-90
VFA1111C-4B93B
R713 119-1011-15 1/10W 100 ohm R725 119-5611-15 1/10W 560 ohm
D715 001-7115-90
VFA1111C-4B93B
R714 119-1011-15 1/10W 100 ohm R726 119-5611-15 1/10W 560 ohm
D716 001-7115-90
VFA1111C-4B93B
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D711 001-7115-91
VUG1111C-4BX3B
D716 001-7115-91
VUG1111C-4BX3B
R719 119-1511-15 1/10W 150 ohm
D712 001-7115-91
VUG1111C-4BX3B
R705 119-8211-15 1/10W 820 ohm R720 119-1511-15 1/10W 150 ohm
D713 001-7115-91
VUG1111C-4BX3B
R706 119-4711-15 1/10W 470 ohm R724 119-8211-15 1/10W 820 ohm
D714 001-7115-91
VUG1111C-4BX3B
R713 119-1511-15 1/10W 150 ohm R725 119-4711-15 1/10W 470 ohm
D715 001-7115-91
VUG1111C-4BX3B
R714 119-1511-15 1/10W 150 ohm
The same parts for PE-3050E-A/B/C
The parts for PE-3050E-A
The parts for PE-3050E-B
The parts for PE-3050E-C
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R830 033-1011-15 1/16W 100 ohm R850 033-1031-15 1/16W 10k ohm R871 032-0140-50
1/10W 10k ohm(F)
R831 033-2221-15 1/16W 2.2k ohm R851 033-1031-15 1/16W 10k ohm R872 119-6221-15 1/10W 6.2k ohm
R832 033-2221-15 1/16W 2.2k ohm R853 119-2721-15 1/10W 2.7k ohm R873 119-1031-15 1/10W 10k ohm
R833 033-2221-15 1/16W 2.2k ohm R854 119-1021-15 1/10W 1k ohm R874 119-6221-15 1/10W 6.2k ohm
R834 119-2201-15 1/10W 22 ohm R855 119-1021-15 1/10W 1k ohm R875 119-6821-15 1/10W 6.8k ohm
R835 033-3321-15 1/16W 3.3k ohm R856 119-1021-15 1/10W 1k ohm R876 033-3331-15 1/16W 33k ohm
R836 033-1511-15 1/16W 150 ohm R857 119-1021-15 1/10W 1k ohm R877 033-3331-15 1/16W 33k ohm
R837 033-2231-15 1/16W 22k ohm R858 033-1031-15 1/16W 10k ohm S501 013-6100-00 SWITCH
R839 119-4701-15 1/10W 47 ohm R859 033-1031-15 1/16W 10k ohm
SUP202
060-0122-20 DSP-141N9S00B
R840 119-3301-15 1/10W 33 ohm R860 033-1031-15 1/16W 10k ohm T101 009-9006-60 0.23mH
R841 119-1511-15 1/10W 150 ohm R861 033-1031-15 1/16W 10k ohm T101 009-9006-70 CHOKE
R842 119-1511-15 1/10W 150 ohm R862 119-6831-15 1/10W 68k ohm X201 061-3013-00 4.33MHz
R845 033-0000-05 0.5A 0 ohm R863 119-2231-15 1/10W 22k ohm X501 061-1056-00 32.768kHz
R846 033-0000-05 0.5A 0 ohm R865 119-3351-15 1/10W 3.3m ohm X502 061-3562-90 13.5MHz
R847 033-0000-05 0.5A 0 ohm R866 033-1031-15 1/16W 10k ohm X801 060-1535-90 16.9344MHz
R848 033-0000-05 0.5A 0 ohm R867 119-1031-15 1/10W 1 0k ohm PWB 039-3207-00 PWB(WITHOUT
R849 033-1031-15 1/16W 10k ohm R870 032-0140-54
1/10W 22k ohm(F)
COMPONENT)
