Clarion DB189RGMP Service Manual

REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ANT2 092-4000-51 ANT-RECEPT C319 043-1735-90 100pF C820 043-1608-90 0.1uF
BL1 941-0227-30 TUNER PACK C320 043-1735-90 100pF C821 043-1804-90 0.1uF
C118 043-1608-90 0.1uF C321 187-1063-35 16V 10uF C822 043-1802-90 0.01uF
C119 043-1608-90 0.1uF C322 187-1063-35 16V 10uF C824 043-1804-90 0.1uF
C120 187-1073-15 6.3V 100uF C337 187-1063-35 16V 10uF C825 043-1824-90 0.22uF
C121 043-1608-90 0.1uF C338 187-1063-35 16V 10uF C826 043-1625-90 0.022uF
C122 187-1073-35 16V 100uF C339 187-1063-35 16V 10uF C827 043-1608-90 0.1uF
C123 043-1608-90 0.1uF C340 187-1063-35 16V 10uF C828 187-1073-15 6.3V 100uF
C124 187-1073-35 16V 100uF C346 043-1841-90 0.047uF C829 043-1608-90 0.1uF
C125 043-1608-90 0.1uF C401 042-1715-00 16V 3300uF C830 043-1804-90 0.1uF
C200 187-1063-35 16V 10uF C413 178-4742-78 0.47uF C831 187-1073-15 6.3V 100uF
C201 043-1804-90 0.1uF C414 178-4742-78 0.47uF C833 189-3373-11 6.3V 330uF
C202 043-1727-90 47pF C415 178-4742-78 0.47uF C834 189-4773-22 10V 470uF
C203 043-1817-90 0.018uF C416 178-4742-78 0.47uF C835 043-1804-90 0.1uF
C204 043-1817-90 0.018uF C421 043-1620-90 4700pF C836 163-4753-55 50V 4.7uF
C205 043-1623-90 560pF C428 187-1063-35 16V 10uF C837 163-4753-55 50V 4.7uF
C206 043-1804-90 0.1uF C435 178-4742-78 0.47uF C838 043-1800-90 1000pF
C207 189-2273-21 10V 220uF C442 187-1053-65 50V 1uF C839 043-1800-90 1000pF
C208 043-1617-90 6800pF C445 172-1041-15 0.1uF C840 043-1800-90 1000pF
C209 187-1073-25 10V 100uF C447 043-1751-90 470pF C841 043-1800-90 1000pF
C210 187-1073-25 10V 100uF C449 043-1751-90 470pF C842 043-1731-90 68pF
C211 043-1804-90 0.1uF C450 043-1751-90 470pF C843 043-1731-90 68pF
C212 043-1804-90 0.1uF C451 043-1751-90 470pF C844 043-1608-90 0.1uF
C213 187-1073-25 10V 100uF C452 043-1751-90 470pF C845 043-1608-90 0.1uF
C214 043-1804-90 0.1uF C453 043-1751-90 470pF C846 043-1608-90 0.1uF
C215 172-6831-15 0.068uF C454 043-1751-90 470pF C847 187-1053-65 50V 1uF
C216 043-1607-90 0.01uF C455 043-1751-90 470pF C848 187-1073-15 6.3V 100uF
C217 043-1607-90 0.01uF C500 187-3363-45 10V 33uF C849 043-1804-90 0.1uF
C218 043-1601-90 100pF C501 168-1052-78 50V 1uF C850 043-1804-90 0.1uF
C219 043-1713-90 12pF C502 043-1608-90 0.1uF C853 189-4773-22 10V 470uF
C220 043-1713-90 12pF C503 043-1608-90 0.1uF C854 043-1841-90 0.047uF
C221 043-1622-90 330pF C504 168-1052-78 50V 1uF C855 043-1608-90 0.1uF
C222 043-1719-90 22pF C505 043-1804-90 0.1uF C856 043-1804-90 0.1uF
C223 043-1804-90 0.1uF C506 043-0540-00 16V 10uF C857 187-1073-15 6.3V 100uF
C224 187-1073-25 10V 100uF C507 163-1063-35 16V 10uF C858 043-1804-90 0.1uF
C226 187-1053-65 50V 1uF C508 043-1710-90 9pF C859 187-1073-15 6.3V 100uF
C227 043-1804-90 0.1uF C509 043-1710-90 9pF C860 187-1073-15 6.3V 100uF
C230 043-1607-90 0.01uF C510 043-1719-90 22pF C861 043-1608-90 0.1uF
C231 187-4763-15 6.3V 47uF C511 043-1719-90 22pF C870 187-1073-35 16V 100uF
C232 043-1802-90 0.01uF C512 043-1607-90 0.01uF D100 001-0592-61 1N5404
C233 187-4753-65 50V 4.7uF C513 043-1601-90 100pF D109 001-0466-61 1A4
C234 043-1735-90 100pF C514 042-1577-00 6.3V 100uF D201 001-1323-90 L1SS355T1G
C235 043-1735-90 100pF C515 043-1607-90 0.01uF D202 001-1323-90 L1SS355T1G
C236 043-1618-90 0.018uF C516 189-1083-12 6.3V 1000uF D302 001-4316-17 LM3Z4V3T1G
C237 043-1625-90 0.022uF C800 187-1073-15 6.3V 100uF D401 001-4316-24 LM3Z8V2T1G
C238 043-1626-90 820pF C801 043-1620-90 4700pF D402 001-1323-90 L1SS355T1G
C239 043-1624-90 680pF C802 043-1802-90 0.01uF D403 001-1323-90 L1SS355T1G
C240 043-1600-90 10pF C803 043-1804-90 0.1uF D500 001-1323-90 L1SS355T1G
C244 043-1625-90 0.022uF C804 043-1804-90 0.1uF D502 001-4301-26 HZU4.7B2
C245 043-1607-90 0.01uF C805 187-3363-25 6.3V 33uF D503 001-1323-90 L1SS355T1G
C250 187-4763-35 16V 47uF C806 043-1804-90 0.1uF D504 001-1323-90 L1SS355T1G
C307 187-1053-65 50V 1uF C807 187-1073-15 6.3V 100uF D505 001-1323-90 L1SS355T1G
C308 187-1053-65 50V 1uF C809 043-1804-90 0.1uF D506 001-1323-90 L1SS355T1G
C309 187-1053-65 50V 1uF C810 043-1804-90 0.1uF D507 001-1323-90 L1SS355T1G
C310 187-1053-65 50V 1uF C811 043-1802-90 0.01uF D509 001-4301-41 HZU7.5B2
C311 187-1053-65 50V 1uF C812 043-1606-90 1000pF D510 001-4301-41 HZU7.5B2
C312 187-1053-65 50V 1uF C813 043-1804-90 0.1uF D511 001-4301-41 HZU7.5B2
C313 187-4763-15 6.3V 47uF C814 043-1607-90 0.01uF D512 001-4301-41 HZU7.5B2
C314 187-1063-35 16V 10uF C815 187-1073-15 6.3V 100uF D521 001-1323-90 L1SS355T1G
C315 043-1735-90 100pF C816 168-1052-78 50V 1uF D801 001-1323-90 L1SS355T1G
C316 043-1735-90 100pF C817 043-1606-90 1000pF D802 001-0644-90 MA113
C317 043-1804-90 0.1uF C818 043-1608-90 0.1uF IC105 051-3349-00 HA13166
C318 187-4763-35 16V 47uF C819 187-1073-15 6.3V 100uF IC201 051-4620-90 LC72725KM
-9-
ELECTRICAL PARTS LIST
Main PWB(B1) section
Note)1. Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
2. Some parts depend on each model. The model name is specified in the description.
DB188/189RMP/DB189RGMP
