Clarion DXZ558RMP User Manual

-14 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C 210
187-3363-25 10V 33uF
D 112
001-4301-41 HZU7.5B2
Q 207
125-2041-93 RT1N241M
C 213
187-1073-35 16V 100uF
D 201
001-0592-61 1N5404
Q 207
125-2027-92 DTC124EUA
C 214
187-1073-15 6.3V 100uF
D 202
001-1310-00 KDS160
Q 208
125-0034-92 RT1P141M
C 215
187-1063-35 16V 10uF
D 203
001-0466-60 1A2
Q 213
125-2041-93 RT1N241M
C 216
042-1631-50 10V 100uF
D 204
001-1310-00 KDS160
Q 213
125-2027-92 DTC124EUA
C 219
166-1011-50 50V 100
p
F
D 205
001-1310-00 KDS160
Q 214
190-1602-00 2SA1602
A
C 220
168-1042-78 50V 0.1uF
D 206
001-4301-26 HZU4.7B2
Q 215
125-2041-93 RT1N241M
C 222
166-1011-50 50V 100
p
F
D 207
001-1310-00 KDS160
Q 215
125-2027-92 DTC124EUA
C 223
166-1011-50 50V 100
p
F
D 208
001-0347-32 MA4056M
Q 216
125-2041-93 RT1N241M
C 300
168-4722-55 50V 4700
p
F
D 210
001-0466-61 1A4
Q 216
125-2027-92 DTC124EUA
C 301
168-4722-55 50V 4700
p
F
D 211
001-0466-61 1A4
Q 217
125-3005-90 KTA1273
C 302
187-2253-65 50V 2.2uF
D 212
001-0466-61 1A4
Q 220
190-1602-00 2SA1602
A
C 303
187-2253-65 50V 2.2uF
D 216
001-1310-00 KDS160
Q 221
125-2041-93 RT1N241M
C 306
187-2253-65 50V 2.2uF
D 501
001-1310-00 KDS160
Q 221
125-2027-92 DTC124EUA
C 307
187-2253-65 50V 2.2uF
D 502
001-1310-00 KDS160
Q 222
190-1365-50 2SA1365
C 308
187-1063-35 16V 10uF
D 504
001-4301-43 HZU8.2B2
Q 222
191-1197-50 2SB1197
K
C 309
187-1063-35 16V 10uF
D 505
001-4301-23 HZU4.3B2
Q 454
125-4012-90 KTD1304
C 310
187-1063-35 16V 10uF
D 600
001-1310-00 KDS160
Q 455
125-4012-90 KTD1304
C 311
187-1063-35 16V 10uF
D 601
001-1310-00 KDS160
Q 456
125-4012-90 KTD1304
C 312
168-4732-78 25V 0.047uF
D 602
001-7062-90 RBR1111C
Q 457
125-4012-90 KTD1304
C 313
168-4732-78 25V 0.047uF
D 801
001-1310-00 KDS160
Q 502
192-4155-49 2SC4155
A
C 314
187-1053-65 50V 1uF
D 802
001-1310-00 KDS160
Q 503
125-2041-96 RT1N436M
C 454
187-2263-35 16V 22uF
IC 1
051-6201-90 LC72146M
Q 503
125-2027-95 DTC143ZUA
C 455
187-2263-35 16V 22uF
IC 101
051-2057-00 TB2906HQ
Q 505
125-0034-96 RT1P436M
C 456
187-2263-35 16V 22uF
IC 200
051-3297-10 BA4916-V2
Q 506
125-0034-96 RT1P436M
C 457
187-2263-35 16V 22uF
IC 302
051-3049-90 HA17558AF
Q 514
125-2041-96 RT1N436M
C 462
168-5612-55 25V 560
p
F
IC 501
051-5030-90 M61523FP
Q 514
125-2027-95 DTC143ZUA
C 463
168-5612-55 25V 560
p
F
IC 600
052-3947-00 M30622MGP-
Q 601
125-2041-93 RT1N241M
C 464
168-5612-55 25V 560
p
F 178GP
Q 601
125-2027-92 DTC124EUA
C 465
168-5612-55 25V 560
p
F
IC 601
051-5437-08 S-80821ANMP
Q 602
125-2041-93 RT1N241M
C 500
187-2253-65 50V 2.2uF
IC 602
051-6600-58 HA12187FP
Q 602
125-2027-92 DTC124EUA
C 501
187-2253-65 50V 2.2uF
IC 603
051-5443-08 BD4850G
Q 603
190-1602-00 2SA1602
A
C 502
187-2253-65 50V 2.2uF
IC 801
051-0350-93 NJM4558M
R5
119-4721-15 1/16W4.7k ohm
C 505
187-2253-65 50V 2.2uF
IC 802
051-4616-90 PT2579S-SN
R6
116-3311-15 1/4W 330 ohm
C 506
187-2253-65 50V 2.2uF
J 600
074-1194-00 13P
R7
119-1231-15 1/16W 12k ohm
C 507
187-2253-65 50V 2.2uF
J 601
076-0648-18 18P
R8
119-2711-15 1/16W 270 ohm
C 508
187-1063-35 16V 10uF
J 900
074-1237-70 20P
R10
119-2221-15 1/16W 2.2k ohm
C 509
187-1073-35 16V 100uF
L1
010-2003-04 30uH(Variable)
R11
119-2221-15 1/16W 2.2k ohm
C 510
168-1042-78 50V 0.1uF
L3
010-6026-50 220uH
R12
119-1021-15 1/16W 1k ohm
C 512
166-2201-50 50V 22
p
FCH
L6
010-6026-50 220uH
R13
119-1031-15 1/16W 10k ohm
C 516
166-2201-50 50V 22
p
FCH
L 200
010-2230-64 2.2uH
R15
119-1021-15 1/16W 1k ohm
C 518
166-2201-50 50V 22
p
FCH
L 507
010-3105-62 1k ohm 100MHz
R16
119-5621-15 1/16W 5.6k ohm
C 519
166-2201-50 50V 22
p
FCH
L 508
010-3105-62 1k ohm 100MHz
R17
119-5631-15 1/16W 56k ohm
C 525
166-1011-50 50V 100
p
F
L 509
010-3105-62 1k ohm 100MHz
R18
119-1021-15 1/16W 1K ohm
C 533
168-1022-55 50V 1000
p
F
L 510
010-3105-62 1k ohm 100MHz
R19
119-1021-15 1/16W 1K ohm
C 537
187-2263-35 16V 22uF
L 601
010-3100-66 2.2uH
R20
119-1021-15 1/16W 1K ohm
C 600
168-1032-55 50V 0.01F
L 602
010-3100-66 2.2uH
R21
119-8201-15 1/16W 82 ohm
C 601
042-0650-00 5.5V 0.1uF
L 603
010-3100-66 2.2uH
R22
119-1041-15 1/16W 100k ohm
C 603
168-1032-55 50V 0.01uF
L 605
010-3100-66 2.2uH
R23
119-3311-15 1/16W 330 ohm
C 605
042-1577-00 6.3V 100uF
L 606
010-3100-66 2.2uH
R24
119-5631-15 1/16W 56k ohm
C 606
168-1022-55 50V 1000
p
F
L 607
010-3100-66 2.2uH
R29
119-1021-15 1/16W 1k ohm
C 607
168-1032-55 50V 0.01uF
L 610
010-3105-62 1k ohm 100MHz
R32
119-1521-15 1/4WS 1.5k ohm
C 608
168-1032-55 50V 0.01uF
L 611
010-3105-62 1k ohm 100MHz
R33
119-1031-15 1/16W 10k ohm
C 609
168-4732-78 25V 0.047uF
Q3
198-0669-00 2SK669
R34
119-1031-15 1/16W 10k ohm
C 612
187-1063-35 16V 10uF
Q4
125-2041-93 RT1N241M
R36
119-1031-15 1/16W 10k ohm
C 619
168-1022-55 50V 1000
p
F
Q4
125-2027-92 DTC124EUA
R37
119-1521-15 1/4WS 1.5k ohm
C 620
168-1022-55 50V 1001
p
F
Q5
192-3440-50 2SC3440
R40
119-1031-15 1/16W 10k ohm
C 622
168-1022-55 50V 1002
p
F
Q6
125-0034-93 RT1P241M
R 100
119-1031-15 1/16W 10k ohm
C 801
168-2232-55 25V 0.022uF
Q7
190-1602-00 2SA1602
A
R 101
119-0000-05 1/16W 0 ohm JW
C 802
166-8211-50 50V 820
p
F
Q8
190-1602-00 2SA1602
A
R 102
119-0000-05 1/16W 0 ohm JW
C 803
166-6811-50 50V 680
p
F
Q9
125-2041-92 RT1N141M
R 103
119-1221-15 1/16W 1.2k ohm
C 804
166-5611-50 50V 560
p
F
Q9
125-2027-91 DTC114EUA
R 106
119-4731-15 1/16W 47k ohm
C 805
166-3311-50 50V 330
p
F
Q10
192-4155-49 2SC4155
A
R 501
119-1021-15 1/16W 1k ohm
C 806
187-2253-65 50V 2.2uF
Q 200
125-4011-90 KTD863
R 110
119-4721-15 1/16W 4.7k ohm
C 808
168-2232-55 25V 0.022uF
Q 201
125-2041-96 RT1N436M
R 111
119-4721-15 1/16W 4.7k ohm
C 809
168-1032-55 50V 0.01uF
Q 201
125-2027-95 DTC143ZUA
R 112
119-4721-15 1/16W 4.7k ohm
C 810
166-4701-50 50V 47
p
F
Q 202
190-1602-00 2SA1602
A
R 113
119-4721-15 1/16W 4.7k ohm
C 811
166-5601-50 50V 56
p
F
Q 203
192-4155-49 2SC4155
A
R 200
119-1231-15 1/16W 12k ohm
C 812
166-1007-50 50V 10
p
F
Q 204
190-1602-00 2SA1602
A
R 201
119-1541-15 1/16W 150k ohm
C 813
187-4763-15
6.3V 47
p
F
Q 205
193-1858-50 2SD1858 Q
,
R
R 202
119-3321-15 1/16W 3.3k ohm
D 111
001-4301-41 HZU7.5B2
Q 206
193-1858-50 2SD1858 Q
,
R
R 203
119-3311-15 1/16W 330 ohm
