English
36
DXZ575USB
10. SPECIFICATIONS
FM Tuner
Frequency Range: 87.9 MHz to 107.9 MHz
Usable Sensitivity: 9 dBf
50dB Quieting Sensitivity: 15 dBf
Alternate Channel Selectivity: 70 dB
Stereo Separation (1 kHz): 35 dB
Frequency Response (±3 dB): 30 Hz to 15 kHz
AM Tuner
Frequency Range: 530 kHz to 1710 kHz
Usable Sensitivity: 25 µV
CD Player
System: Compact disc digital audio system
Usable Discs: Compact disc
Frequency Response (±1 dB): 5 Hz to 20 kHz
Dynamic Range (1 kHz): 95 dB
Harmonic Distortion: 0.01%
Audio
Maximum Power Output: 212 W (53 W
✕
4 ch)
Bass Control Action (80 Hz): +14 dB, –14 dB
Treble Control Action (10 kHz): +12 dB, –12 dB
Line Output Level (CD 1 kHz): 5.7 V
General
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable), negative
ground
Current Consumption: Less than 15 A
Speaker Impedance: 4
Ω
(4
Ω
to 8
Ω
allowable)
Auto Antenna Rated Current: 500 mA or less
Weight / Source unit: 2.75 lb. (1.6 kg)
Weight / Remote control unit:
1.41 oz. (40 g) (including battery)
Dimensions / Source unit:
7" (Width)
✕
2" (Height)
✕
6-1/8" (Depth)
[178 (W)
✕
50 (H)
✕
158 (D) mm]
Dimensions / Remote control unit:
1-3/4" (Width)
✕
4-5/16" (Height)
✕
7/16"
(Depth)
[44 (W)
✕
113 (H)
✕
11 (D) mm]
Note:
• Specifications and design are subject to change without notice for further improvement.
Power Output :
19 W RMS x 4 Channels at 4 Ω
and 1 % THD+N
Signal to Noise Ratio:
83 dBA (reference: 1 W into 4 Ω)
DXZ575USB_EN.book 36 ページ ２００６年１２月２５日 月曜日 午後１２時５７分
