P.EQ basic menu setting values
F: Center frequency, Q: Q curve, G: Gain (output level)
3-6. Push the [P.CH] button upward or
downward to adjust the frequency, the gain
and the Q.
3-7. Press and hold the [ ] button for 2
seconds or longer to store the adjusting in
USER memory and auto return to the
USER mode.
When speaker system is “3WAY” or
“2WAY”:
3-2. Press the [MENU] button and select from:
“BAND1” ➜ “BAND2” ➜ “BAND3” ➜
“BAND1”...
3-3. Push the [SEEK PANEL] leftward or
rightward and select from:
3-4. Push the [P.CH] button upward or
downward to adjust the frequency, the gain
and the Q.
3-5. Press the [ ] button to return to the
previous mode.
Note:
• Press and hold the [] button for 2
seconds or longer to copy the settings between
left and right (for 3WAY or 2WAY speaker
system).
No. (car type)
Parametric Equalizer Parameters (default)
Channel
Band 1 Band 2 Band 3
FQG FQG FQG
1 (SEDAN-1) Front 250 Hz 3 –8 dB 2 kHz 1 –4 dB 5 kHz 1 –4 dB
Rear 250 Hz 3 –10 dB 1.25 kHz 5 0 dB 8 kHz 5 0 dB
2 (SEDAN-2) Front 250 Hz 7 –10 dB 800 Hz 3 –4 dB 8 kHz 1 –5 dB
Rear 80 Hz 7 +3 dB 125 Hz 5 –12 dB 1.25 kHz 5 0 dB
3
(MINI VAN-1)
Front 125 Hz 5 –4 dB 1.25 kHz 3 –4 dB 2 kHz 7 +3 dB
Rear 250 Hz 1 –6 dB 630 Hz 3 –4 dB 8 kHz 5 0 dB
4
(MINI VAN-2)
Front 250 Hz 3 –4 dB 1.25 kHz 3 –8 dB 80 Hz 3 +3 dB
Rear 250 Hz 3 –8 dB 500 Hz 5 –5 dB 8 kHz 5 0 dB
5 (WAGON) Front 250 Hz 3 –8 dB 1 kHz 3 –8 dB 10 kHz 1 –6 dB
Rear 250 Hz 3 –8 dB 800 Hz 1 –8 dB 8 kHz 5 0 dB
6 (USER) Front 500 Hz 1 0 dB 1 kHz 1 0 dB 5 kHz 1 0 dB
Rear 500 Hz 1 0 dB 1 kHz 1 0 dB 5 kHz 1 0 dB
• LEFT
• FREQUENCY
• GAIN
• Q
• RIGHT
• FREQUENCY
• GAIN
• Q
• LEFT
3WAY mode
(Frequency)
(Gain)
(Q curve)
(Front speaker (left))
(Front speaker (right))
Items Adjustable
range
Initial value
FREQUENCY
(Frequency)
20 Hz to 20 kHz 500 Hz
GAIN (Gain) –12 dB to +12
dB
0 dB
Q (Q curve) 1, 3, 5, 7, 20 1
• LEFT
• FREQUENCY
• GAIN
• Q
2WAY mode
• RIGHT
• FREQUENCY
• GAIN
• Q
• LEFT
(Front speaker (left))
(Front speaker (right))
(Frequency)
(Gain)
(Q curve)
