Clarion EQS746 User Manual

14 EQS746
English
8. Specifications
Note
The technical data and the design of the equipment may change without
prior notice for the sake of technical improvements.
Graphic center frequencies: 50Hz, 125Hz, 315Hz, 750Hz, 2.2Hz, 6kHz, 16kHz
Boost/cut: 12dB
S/N ratio: 100dB
Frequency response: 10Hz-50kHz +/-1dB
Maximum output voltage: 7V
THD: 0.005%
Input sensitivity: 50mV - 3V
Head room: 20dB
Input impedance: 20kOhms
Output impedance: 2kOhms
Stereo separation: 82dB/1kHz
Operating voltage: 11V-15V negative ground
Size: 7” wide by 4 1/8” deep by 1” high
EQS746_OwnersManual.pmd 2005-12-02, 16:1314

Clarion EQS746 Specifications

General

AUX in	Yes
Output voltage	7 V
Product color	Black
