Clarion EQS746 User Manual

6 EQS746
English
3. CONTROLS
Front panel controls
Rear panel connections
Top panel
Subwoofer volume
AUX (auxiliary) switch: Press to
select auxiliary or main inputs
Master volume
Fader control: Use to balance sound
between front and rear speakers
Equalizer gain controls
To adjust gain, rotate control to desired setting
AUX gain control: Gain adjustment for left and right
auxiliary input
Low-pass frequency switch (60/90Hz)
+12V
REM
GND
Front out
L R
L R
Rear out
Main in
L R
L R
Aux in
Sub out
L R
EQS746_OwnersManual.pmd 2005-12-02, 16:136

Clarion EQS746 Specifications

General

AUX in	Yes
Output voltage	7 V
Product color	Black
