Clarion M335 User Manual

- 12 -- 12 -
- 12 -- 12 -
- 12 -
M335/M235M335/M235
M335/M235M335/M235
M335/M235
Q421 125-0199-92 KRA102S
Q901 125-2199-93 KRC103S
Q902 125-3006-90 KTA1281
Q903 125-3004-90 KTA1504
Q904 125-4010-90 KTC3875GR
Q905 125-2199-92 KRC102S
Q906 125-0199-92 KRA102S
Q907 102-3420-00 2SC3420
Q908 125-0199-92 KRA102S
Q909 125-4011-90 KTD863YAT
Q910 125-4011-90 KTD863YAT
Q911 125-2199-93 KRC103S
Q912 125-3004-90 KTA1504
Q913 125-4011-90 KTD863YAT
Q914 125-4011-90 KTD863YAT
Q915 125-4011-90 KTD863YAT
Q916 125-3004-90 KTA1504
Q917 125-4010-90 KTC3875GR
Q918 125-0199-92 KRA102S
Q919 125-4010-90 KTC3875GR
Q920 125-0199-92 KRA102S
Q921 125-4010-90 KTC3875GR
Q922 125-2199-93 KRC103S
Q923 125-3005-90 KTA1237
Q924 125-2199-92 KRC102S
Q925 125-4011-90 KTD863YAT
Q928 125-3004-90 KTA1504
RCA401 075-0388-00 JACK
R101 119-2221-15 1/16W 2.2K ohm
R102 119-1011-15 1/16W 100 ohm
R103 119-2221-15 1/16W 2.2K ohm
R104 119-4741-15 1/16W 470K ohm
R105 119-1021-15 1/16W 1K ohm
R106 119-1831-15 1/16W 18K ohm
R107 119-1031-15 1/16W 10K ohm
R108 111-2221-98 1/4WS 2.2K ohm
R109 119-1031-15 1/16W 10K ohm
R110 111-2221-98 1/4WS 2.2K ohm
R111 119-1021-15 1/16W 1K ohm
R112 119-1021-15 1/16W 1K ohm
R113 111-4721-98 1/4WS 4.7K ohm
R116 060-0108-90 1/4WS 0 ohm
R201 119-1041-15 1/16W 100K ohm
R202 119-2221-15 1/16W 2.2K ohm
R203 119-2221-15 1/16W 2.2K ohm
R204 119-1021-15 1/16W 1K ohm
R205 119-1031-15 1/16W 10K ohm
R206 119-5631-15 1/16W 56K ohm
R207 119-4731-15 1/16W 47K ohm
R208 119-1031-15 1/16W 10K ohm
R209 119-1031-15 1/16W 10K ohm
R210 119-2231-15 1/16W 22K ohm
R211 119-2231-15 1/16W 22K ohm
R212 119-1041-15 1/16W 100K ohm
R213 119-1031-15 1/16W 10K ohm #
R214 119-1031-15 1/16W 10K ohm
R217 119-1031-15 1/16W 10K ohm
R218 119-4721-15 1/16W 4.7K ohm
R219 119-4721-15 1/16W 4.7K ohm
R220 119-4731-15 1/16W 47K ohm
R221 119-1041-15 1/16W 100K ohm
R222 119-4731-15 1/16W 47K ohm
R223 119-4731-15 1/16W 47K ohm
R224 119-1041-15 1/16W 100K ohm
R225 119-1031-15 1/16W 10K ohm
R226 119-1031-15 1/16W 10K ohm
R227 119-0000-05 1/16W 0 ohm *
R228 119-1031-15 1/16W 10K ohm
R229 119-0000-05 1/16W 0 ohm
R232 119-1021-15 1/16W 1K ohm
R233 119-1021-15 1/16W 1K ohm
R234 119-1021-15 1/16W 1K ohm
R235 119-1021-15 1/16W 1K ohm
R236 119-1021-15 1/16W 1K ohm
R241 119-1021-51 1/16W 1K ohm #
R242 119-1021-51 1/16W 1K ohm #
R243 119-1021-51 1/16W 1K ohm #
R248 119-1031-15 10K #
R250 119-0000-05 1/16W ohm #
R401 119-1031-15 1/16W 10K ohm
R402 119-3311-15 1/16W 330 ohm
R403 119-5621-15 1/16W 5.6K ohm
R404 119-0000-05 1/16W 0 ohm
R411 119-1031-15 1/16W 10K ohm
R412 119-3311-15 1/16W 330 ohm
R413 119-5621-15 1/16W 5.6K ohm
R414 119-0000-05 1/16W 0 ohm
R421 119-4721-15 1/16W 4.7K ohm
R501 119-1031-15 1/16W 10K ohm
R502 119-1831-15 1/16W 18K ohm
R503 119-5621-15 1/16W 5.6K ohm
R504 119-1021-15 1/16W 1K ohm
R511 119-1031-15 1/16W 10K ohm
R512 119-1831-15 1/16W 18K ohm
R513 119-5621-15 1/16W 5.6K ohm
R514 119-1021-15 1/16W 1K ohm
R531 119-3901-15 1/16W 39 ohm
R532 119-3901-15 1/16W 39 ohm
R533 119-3901-15 1/16W 39 ohm
R534 119-3901-15 1/16W 39 ohm
R601 119-2221-15 1/16W 2.2K ohm
R602 119-2221-15 1/16W 2.2K ohm
R603 119-2291-15 1/16W 2.2 ohm
R604 119-2291-15 1/16W 2.2 ohm
R605 119-2291-15 1/16W 2.2 ohm
R606 119-2291-15 1/16W 2.2 ohm
R611 119-2221-15 1/16W 2.2K ohm
R612 119-2221-15 1/16W 2.2K ohm
R613 119-2291-15 1/16W 2.2 ohm
R614 119-2291-15 1/16W 2.2 ohm
R615 119-2291-15 1/16W 2.2 ohm
R616 119-2291-15 1/16W 2.2 ohm
R621 119-1231-15 1/16W 12K ohm
R622 119-1031-15 1/16W 10K ohm
R901 111-1521-98 1/4WS 1.5K ohm
R902 111-1221-98 1/4WS 1.2K ohm
R903 119-1031-15 1/16W 10K ohm
R904 111-1591-98 1/4WS 1.5 ohm
R905 111-1591-98 1/4WS 1.5 ohm
R906 111-1591-98 1/4WS 1.5 ohm
R907 111-1591-98 1/4WS 1.5 ohm
R908 119-1031-15 1/16W 10K ohm
R909 119-3321-15 1/16W 3.3K ohm
R910 119-3321-15 1/16W 3.3K ohm
R911 119-2231-15 1/16W 22K ohm
R912 111-4711-98 1/4WS 470 ohm
R913 111-4711-98 1/4WS 470 ohm
R914 111-2211-98 1/4WS 220 ohm
R915 111-2291-98 1/4W 2.2 ohm
R916 111-2291-98 1/4WS 2.2 ohm
R917 119-1031-15 1/16W 10K ohm
R918 111-3921-98 1/4WS 3.9K ohm
R919 111-8211-98 1/4WS 820 ohm
R920 111-8211-98 1/4WS 820 ohm
R921 111-2291-98 1/4WS 2.2 ohm
R922 111-2291-98 1/4WS 2.2 ohm
R923 111-1021-98 1/4WS 1K ohm
R924 119-1231-15 1/16W 12K ohm
R925 119-1031-15 1/16W 10K ohm
R926 119-1021-15 1/16W 1K ohm
R927 119-4721-15 1/16W 4.7K ohm
R928 119-1031-15 1/16W 10K ohm
R929 119-1031-15 1/16W 10K ohm
R930 119-1031-15 1/16W 10K ohm
R931 119-4721-15 1/16W 4.7K ohm
R932 119-2231-15 1/16W 22K ohm
R933 111-2231-98 1/4WS 22K ohm
R934 119-4731-15 1/16W 47K ohm
R935 111-1021-98 1/4WS 1K ohm
R936 119-1031-15 1/16W 10K ohm
R937 111-4711-98 1/4WS 470 ohm
R938 119-1031-15 1/16W 10K ohm
R939 119-2231-15 1/16W 22K ohm
R940 111-3321-98 1/4WS 3.3K ohm
R951 060-0108-90 1/4WS 0 ohm
R952 060-0108-90 1/4WS 0 ohm
SUP101 060-0122-20 DSP-141N-S00B
T901 009-9006-60 CHOKE
X101 061-1064-00 4.5MHz
X201 061-1064-00 4.5MHz
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION
Main PWB (Switch) (B2)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION
C1 168-1022-55 50V 1000pF
C2 168-4732-55 50V 0.047uF C3 168-4732-55 50V 0.047uF
