Clarion M335 User Manual

- 11 -- 11 -
- 11 -- 11 -
- 11 -
M335/M235M335/M235
M335/M235M335/M235
M335/M235
ANT101 092-4000-51 ANT-RECEP
BL101 880-2090RI TUNER
C101 166-2201-50 50V 22pF
C102 168-2201-50 50V 22pF
C103 168-1032-55 50V 0.01uF
C104 168-1032-55 50V 0.01uF
C105 168-1032-55 50V 0.01uF
C106 182-1073-25 10V 100uF
C108 168-1032-55 50V 0.01uF
C109 182-1073-25 10V 100uF
C110 182-1073-25 10V 100uF
C111 168-1032-55 50V 0.01uF
C112 168-6822-55 50V 6800pF
C113 168-2732-55 50V 0.027uF
C114 168-2732-55 50V 0.027uF
C115 168-1022-55 50V 1000pF
C116 168-2232-55 50V 0.022uF
C117 182-1053-65 50V 1uF
C118 168-1532-55 50V 0.015uF
C119 168-1032-55 50V 0.01pF
C120 182-3353-65 50V 3.3uF
C121 168-1032-55 50V 0.01uF
C132 168-1045-56 50V 0.1uF
C201 168-1032-55 50V 0.01uF
C202 168-1032-55 50V 0.01pF
C203 168-1045-56 35V 0.1uF
C204 168-1045-56 25V 0.1uF
C205 166-2201-50 50V 22pF
C206 166-2201-50 50V 22pF
C207 166-3311-50 50V 330pF
C208 166-1011-50 50V 100pF
C209 166-1011-50 50V 100pF
C210 166-1011-50 50V 100pF
C211 168-1022-55 50V 1000pF
C212 182-1073-15 6.3V 100uF
C222 168-4732-78 25V 0.047uF
C225 166-1011-50 50V 100pF
C401 182-1063-35 16V 10uF
C402 166-4711-50 50V 470pF
C411 182-1063-35 16V 10uF
C412 166-4711-50 50V 470pF
C501 182-2253-65 50V 2.2uF
C502 182-2253-65 50V 2.2uF
C503 182-2253-65 50V 2.2uF
C504 178-4742-78 25V 0.47uF
C505 168-1045-56 50V 0.1uF
C506 168-1045-56 50V 0.1uF
C507 168-2722-55 50V 2700pF
C508 168-1032-55 50V 0.01uF
C510 168-2222-55 50V 2200pF
C511 182-2253-65 50V 2.2uF
C512 182-2253-65 50V 2.2uF
C513 182-2253-65 50V 2.2uF
C514 178-4742-78 25V 0.47uF
C515 168-1045-56 50V 0.1uF
C516 168-1045-56 50V 0.1uF
C517 168-2722-55 50V 2700pF
C518 168-1032-55 50V 0.01uF
C520 168-2222-55 50V 2200pF
C521 182-2263-35 16V 22uF
C531 166-1011-50 50V 100pF
C532 166-1011-50 50V 100pF
C533 166-1011-50 50V 100pF
C534 166-1011-50 50V 100pF
C535 166-1011-50 50V 100pF
C602 178-4742-78 25V 0.47uF
C603 178-4742-78 25V 0.47uF
C604 172-1041-15 50V 0.1uF
C605 172-1041-15 50V 0.1uF
C606 172-1041-15 50V 0.1uF
C607 172-1041-15 50V 0.1uF
C608 182-1063-35 16V 10uF
C609 182-1063-35 16V 10uF
C612 178-4742-78 25V 0.47uF
C613 178-4742-78 25V 0.47uF
C614 172-1041-15 50V 0.1uF
C615 172-1041-15 50V 0.1uF
C616 172-1041-15 50V 0.1uF
C617 172-1041-15 50V 0.1uF
C618 182-1063-35 16V 10uF
C619 182-1063-35 16V 10uF
C221 182-4743-63 16V 47pF
C622 182-4763-35 16V 47uF
C623 182-2263-35 16V 22uF
C624 182-3343-65 50V 0.33uF
C625 166-4711-50 50V 470pF
C626 166-4711-50 50V 470pF
C627 166-4711-50 50V 470pF
C628 166-4711-50 50V 470pF
C629 166-4711-50 50V 470pF
C630 166-4711-50 50V 470pF
C631 166-4711-50 50V 470pF
C632 166-4711-50 50V 470pF
C901 184-2283-32 16V 2200uF
C902 172-1041-15 50V 0.1uF
C903 182-1063-35 16V 10uF
C904 042-0598-90 10V 470uF
C905 182-2263-35 16V 22uF
C906 182-1073-15 6.3V 100uF
C907 182-1073-25 10V 100uF
C908 042-0452-81 10V 220uF
C909 182-1063-35 16V 10uF
C910 182-1073-25 10V 100uF
C911 168-1045-56 50V 0.1uF
C912 182-4743-65 50V 0.47uF
C914 168-1032-55 50V 0.01uF
C915 182-1063-35 16V 10uF
D201 001-0347-35 MA4062M
D202 001-0347-40 MA4075L
D204 001-0339-90 1SS119
D205 001-0529-41 MA8075M
D206 001-0529-41 MA8075M
D601 001-0466-90 S5688B
D602 001-0466-90 S5688B
D603 001-0466-90 S5688B
D604 001-0466-90 S5688B
D605 001-0466-90 S5688B
D606 001-0466-90 S5688B
D607 001-0466-90 S5688B
D608 001-0466-90 S5688B
D901 001-0592-00 RM4Z
D902 001-0330-90 1SS119
D903 001-0466-91 S5688G
D904 001-0330-90 1SS119
D905 001-0347-45 MA4082H
D906 001-0347-32 MA4056M
D907 001-0347-46 MA4091L
D908 001-0330-90 1SS119
D909 001-0330-90 1SS119
D910 001-0347-36 MA4062H
D911 001-0330-90 1SS119
D912 001-0330-90 1SS119
D913 001-0347-40 MA4075L
D914 001-0347-25 MA4047L
D915 001-0330-90 1SS119
D916 001-0330-90 1SS119
D917 001-0330-90 1SS119
D918 001-0347-35 MA4062M
D920 001-0347-46 MA4091L
IC201 052-1934-10 uPD178078GF
-582-3BA
IC202 051-7400-08 HD74LS07 #
IC501 051-5031-90 PTC2313
IC601 051-2050-01 LA47532
J201 074-1316-12 OUTLET SOCKET
J203 855-1465-60 SOCKET
J701 074-9010-26 OUTLET SOCKET
J901 074-1214-00 OUTLET SOCKET
L101 010-2003-04 COIL
L201 010-2330-86 220uH
L202 010-2330-62 2.2uH #
L203 010-2330-62 2.2uH #
L204 010-2330-62 2.2uH #
L205 010-2330-86 220uH #
L601 010-3001-63 5.6uH
L602 010-3001-63 5.6uH
L603 010-2001-63 5.6uH
L604 010-3001-63 5.6uH
Q101 125-2199-93 KRC103S
Q102 125-3004-90 KTA1504
Q103 125-3004-90 KTA1504
Q104 125-4010-90 KTC3875GR
Q105 125-4010-90 KTC3875GR
Q401 125-4010-90 KTC3875GR
Q411 125-4010-90 KTC3875GR
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ELECTRICAL PARTS LIST
Main PWB Section (B1)
Remarks:- #: For PE-2587B-A only *: For PE-2587B-B only
REF No. PART No. DESCRIPTION
Note:- Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
