NP509
English
Thank you for purchasing the Clarion NP509.
• Please read this manual thoroughly before operating this equipment.
• After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
• Check the contents of the enclosed warranty card and keep it carefully with this manual.
Contents
SPECIFICATIONS ............................................................................................................... 3
INSTALLATION AND WIRE CONNECTION MANUAL...................................................... 4
Safety Precautions ......................................................................................................... 4
Package Contents.......................................................................................................... 6
Name and Function of the Controls................................................................................ 6
Installing the Navigation Unit.......................................................................................... 7
Installing the GPS Anttenna ........................................................................................... 7
Wire Connection............................................................................................................. 9
Dimensions of the Main Unit:
5-9/32” Width (134mm) × 1-11/64” Height (29.6mm) × 5-5/8” Depth (143mm)
Weight of the Main Unit: 500g
* These specifications and designs are subject to change without notice for improvement purposes.
SPECIFICATIONS
