9
NP509
English
Wire Connection
Example of connecti
ng to the VZ509
WARNING
Be sure to read the section “Safety Precautions”
be
fore installation or connection op
erations.
3A
Fuse
Main power supply
Connect to the +12V power supply
where power source is alw
ays supplied.
No connection
No connection
No connection
NP509
VZ509
Ground
Connect to a metal par
t of the vehicle to
connect ground.
3
GPS antenna
2
P
ow
er supply cord
4
System cable
Y
ello
w
White
White/blac
k
Black
Red
8
10
Table of Contents
Specifications
3
Table of Contents
3
Installation and Wire Connection Manual
4
Safety Precautions
4
Package Contents
6
Name and Function of the Controls
6
Installing the Navigation Unit
7
Installing the GPS Anttenna
7
Wire Connection
9
