Installing the GPS Anttenna
8
NP509
English
1. Stick the double-sided tape to the bottom face of the GPS antenna.
2. Mount the GPS antenna.
Stick it surely on a flat plane of the dashboard towards the center of the road where GPS signal
interruption is minimized.
3. Wire the GPS antenna cord.
Fasten the cord using the cord holders.
(Shows an example in case of the left-hand traffic.)
Double-sided
tape
Bottom face of the GPS antenna
GPS antenna
Stick it on a horizontal place of
the dashboard towards the
center of the road.
Cord holder
