Clarion PP-2515L User Manual

- 10 -PP-2515L
D1107 001-7048-96 RAY1112H-75M
D1108 001-7048-96 RAY1112H-75M
D1109 001-7048-96 RAY1112H-75M
D1110 001-7048-96 RAY1112H-75M
D1111 001-7048-96 RAY1112H-75M
D1112 001-7048-96 RAY1112H-75M
D1113 001-7048-96 RAY1112H-75M
D1114 001-7048-96 RAY1112H-75M
D1115 001-7048-96 RAY1112H-75M
D1116 001-7048-96 RAY1112H-75M
D1117 001-7063-91 RAY1102W
D1118 001-7063-91 RAY1102W
D1119 001-7063-91 RAY1102W
D1120 001-7063-91 RAY1102W
D1121 001-7063-91 RAY1102W
D1122 001-7063-91 RAY1102W
D1123 001-7063-91 RAY1102W
D1124 001-7063-91 RAY1102W
D1125 001-7063-91 RAY1102W
D1126 001-7063-91 RAY1102W
D1127 001-7063-91 RAY1102W
D1128 001-7063-91 RAY1102W
D1129 001-7063-91 RAY1102W
D1130 001-7063-91 RAY1102W
D1131 001-7063-91 RAY1102W
D1132 001-7063-91 RAY1102W
D1133 001-7063-91 RAY1102W
D1134 001-7063-91 RAY1102W
D1135 001-7063-91 RAY1102W
D1136 001-7063-91 RAY1102W
D1137 001-7063-91 RAY1102W
D1145 001-0516-90 MA111
D1146 001-0516-90 MA111
D1147 001-0516-90 MA111
D1148 001-0516-90 MA111
D1149 001-0516-90 MA111
D1160 001-0529-44 MA8082-M
D1161 001-0529-44 MA8082-M
D1162 001-0529-44 MA8082-M
D1163 001-0529-44 MA8082-M
D1164 001-0529-44 MA8082-M
D1165 001-0529-44 MA8082-M
D1166 001-0529-44 MA8082-M
D1167 001-0529-44 MA8082-M
D1168 001-0529-44 MA8082-M
IC1101 051-6064-00 LC75883W
LCD101 379-1247-30 LCD
P1101 074-1151-14 14P
R1101 119-6831-15 1/16W 68k ohm
R1102 119-8211-15 1/16W 820 ohm
R1103 119-8211-15 1/16W 820 ohm
R1104 119-8211-15 1/16W 820 ohm
R1105 119-8211-15 1/16W 820 ohm
R1106 119-8211-15 1/16W 820 ohm
R1107 119-8211-15 1/16W 820 ohm
R1108 119-8211-15 1/16W 820 ohm
R1109 116-5611-15 1/8W 560 ohm
R1110 116-5611-15 1/8W 560 ohm
R1111 116-5611-15 1/8W 560 ohm
R1112 116-5611-15 1/8W 560 ohm
R1113 116-5611-15 1/8W 560 ohm
R1114 116-5611-15 1/8W 560 ohm
R1115 116-5611-15 1/8W 560 ohm
R1116 116-5611-15 1/8W 560 ohm
S1101 013-6311-50 SWITCH
S1102 013-6311-50 SWITCH
S1103 013-6311-50 SWITCH
S1104 013-6311-50 SWITCH
S1105 013-6311-50 SWITCH
S1106 013-6311-50 SWITCH
S1107 013-6311-50 SWITCH
S1108 013-6311-50 SWITCH
S1109 013-6311-50 SWITCH
S1110 013-6311-50 SWITCH
S1111 013-6311-50 SWITCH
S1112 013-6311-50 SWITCH
S1113 013-6311-50 SWITCH
S1114 013-6311-50 SWITCH
S1115 013-6311-50 SWITCH
S1116 013-6311-50 SWITCH
S1117 013-6311-50 SWITCH
S1118 013-6311-50 SWITCH
S1119 013-6302-51 SKQMAL
VR1101 016-0013-03 ROTARY ENCODER
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Sub PWB(B3) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
J1001 074-1013-30 12P
J1002 074-1298-10 8P
P1001 076-0544-10 10P
P1002 076-0544-08 8P
CD PWB(B4) section:CD mechanism
C101 168-1042-78 0.1uF
C102 045-4701-50 47pF
C103 046-4722-58 4700pF
C104 168-1042-78 0.1uF
C105 046-1532-78 0.015uF
C106 046-1032-78 0.01uF
C107 046-1032-78 0.01uF
C108 046-4722-58 4700pF
C109 046-1522-58 1500pF
C110 046-3332-78 0.033uF
C111 168-1042-78 0.1uF
C112 046-3332-78 0.033uF
C113 168-1042-78 0.1uF
C114 168-1042-78 0.1uF
C115 046-4712-58 470pF
C116 046-4712-58 470pF
C117 043-0533-50 0.047uF
C118 043-0533-50 0.047uF
C119 045-2701-50 27pF
C120 045-1801-50 18pF
C121 163-1063-35 16V10uF
C122 178-1052-78 1uF
C123 046-1032-78 0.01uF
C124 163-1073-05 4V100uF
C125 168-1042-78 0.1uF
C126 168-1042-78 0.1uF
C129 178-1052-78 1uF
C201 163-3363-05 4V33uF
C202 168-1042-78 0.1uF
C203 178-1052-78 1uF
C204 163-1073-05 4V100uF
C205 163-3363-05 4V33uF
C206 168-1042-78 0.1uF
C207 043-0533-50 0.047uF
C208 046-6822-58 6800pF
C209 168-1042-78 0.1uF
C210 043-0533-50 0.047uF
C211 168-1042-78 0.1uF
C212 168-1042-78 0.1uF
C213 045-5096-50 5pF
C214 045-5601-50 56pF
C215 043-0533-50 0.047uF
C216 178-1052-78 1uF
C217 045-1011-50 100pF
C301 163-1073-35 16V100uF
C302 168-1042-78 0.1uF
C303 043-0533-50 0.047uF
D201 001-0516-90 MA111
IC101 051-6376-00 TC94A14FA
IC102 051-3279-90 BA033LBSG
IC201 051-5710-90 TA2157F
IC301 051-6049-08 BA5983FP-E2
J101 074-1228-76 26P
J201 074-1138-65 15P
J301 074-1138-60 10P
L101 010-2285-57 BLM21B102SPT
L102 010-2285-57 BLM21B102SPT
L103 010-2285-57 BLM21B102SPT
L104 010-2285-57 BLM21B102SPT
L105 010-2285-57 BLM21B102SPT
L401 010-3050-93 10μH
Q201 131-1188-50 2SB1188
R102 033-5621-15 1/16W 5.6k ohm
R104 033-4731-15 1/16W 47k ohm
R105 033-1041-15 1/16W 100k ohm
R108 033-1531-15 1/16W 15k ohm
R109 033-1031-15 1/16W 10k ohm
R110 033-1051-15 1/16W 1M ohm
R111 033-3321-15 1/16W 3.3k ohm
R114 033-2211-15 1/16W 220 ohm
R115 033-2211-15 1/16W 220 ohm
R116 033-1031-15 1/16W 10k ohm
R117 033-1021-15 1/16W 1k ohm
R131 033-4711-15 1/16W 470 ohm
R132 033-2211-15 1/16W 220 ohm
R201 117-2201-15 1/10W 22 ohm
R202 117-2201-15 1/10W 22 ohm
R203 033-1041-15 1/16W 100k ohm
R204 033-1041-15 1/16W 100k ohm
R205 033-1041-15 1/16W 100k ohm
R206 033-1041-15 1/16W 100k ohm
R207 033-1041-15 1/16W 100k ohm
R208 033-8231-15 1/16W 82k ohm
R209 033-6811-15 1/16W 680 ohm
R210 033-6831-15 1/16W 68k ohm
R211 033-1831-15 1/16W 18k ohm
R212 033-2721-15 1/16W 2.7k ohm
R213 033-1011-15 1/16W 100 ohm
R214 033-1021-15 1/16W 1k ohm
R215 033-1031-15 1/16W 10k ohm
R217 033-1041-15 1/16W 100k ohm
R218 033-2211-15 1/16W 220 ohm
R301 117-6811-15 1/16W 680 ohm
R304 033-3921-15 1/16W 3.9k ohm
R305 033-3921-15 1/16W 3.9k ohm
R306 033-1041-15 1/16W 100k ohm
R307 033-2211-15 1/16W 220 ohm
X102 060-1528-90 16.934M
LED PWB(B5) section:CD mechanism
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D1 001-7058-90 AN1105W-RR
D2 001-7058-90 AN1105W-RR
J1 074-1138-60 10P
Q1 060-4015-90 PS1192H
Q2 060-4015-90 PS1192H
S1 013-7414-50 CHUCKING
S2 013-7413-50 LIMIT
